Changtong Diamond Wire Cutting Machine 1830*2800*2650mm - China′s State-of-The-Art Equipment

Product Description

Equipment use: Meticulously designed to dramatically boost cutting efficiency for our esteemed clients, this model features an impressive roller length of 690mm and a versatile table size of 170/145mm*690mm*160mm*2 version. Crafted to expertly manage products with thickness variations from 0.3mm to 65mm, this machine is the epitome of cutting-edge precision and technological excellence.
CHTXQ-690F Double Plate Multi-Wire Cutting Machine: Product Features
1. Enjoy superior durability and enhanced performance with our four independently driven motors that power each roller. This pioneering design converts each roller into a dynamic drive shaft, effectively minimizing steel line wear and significantly extending the lifespan of the rollers. The roller bracket's mounting hole is precision-crafted using a processing center mold to maintain exact spindle coaxial installation standards.
2. Access intuitive cutting data with the optional integration of an LED display, enhancing the user experience and efficiency.
3. Simplified material management is achieved through a bottom-up cutting approach, streamlining the process of loading and unloading beneath the table.
4. Versatile machine options available: Opt for the high-speed machine to achieve unparalleled speed and efficiency, or choose the standard model. High-speed options provide exceptional line speeds and enhanced cutting efficiency, suitable for thinner diamond lines on identical materials.
5. The adaptable transverse movement capability allows the table to effortlessly shift back and forth, enabling versatile tile cutting with the precision of single-line cutting for various applications.
6. Boasting an expansive loading area with dimensions of 170/145mm*690mm*160mm*2 version, this design substantially amplifies cutting efficiency, accommodating a wide range of materials.
7. Featuring remarkable spindle precision with an accuracy of ≤0.01mm, this design is reinforced by a patented dust system structure (Patent No. ZL201320681902.7) ensuring stable operation and effortless disassembly.
8. The design is intuitive and user-friendly, highlighted by features like an automatic lifting shield and a fully expanded workbench, which simplify material handling processes from loading and unloading to rolling.

	unit	parameter
Maximum Worksize	mm	170/145*690*160*2
cutting thickness	mm	0.6~65
running speed	m/min	0~2200
Table lift stroke	mm	220
Table cutting feed speed	mm/hour	0.1~100
The amount of wire output from the supply wheel	Km	30(φ0.2diamond wire)
Diamond diameter	mm	φ0.06~φ0.35axle
Roller outside diameter*number of axles	mm	φ155/φ180*690*4
boundary dimension	mm	≈1830*2800*2650
machine weight	Kg	6500~115000
power		AC380V/50HZ three-phase four-wire
Total machine power rating	Kw	54 above

Introducing a revolutionary double-station multi-wire cutting marvel, expertly adept at diamond wire processing for dual plate materials in a seamless single operation. With a roller length of 690mm, it offers a maximum cutting area of 220mm*690mm*160mm*2 version. This machine excels with a rotary tool holder, providing dual cutting functionalities—single and multi-line, ideally suited for processing hard and brittle materials into straight sheets.
Discover the exceptional capabilities of this multi-line cutting machine, custom-designed for diamond line processing. Featuring a 570mm roller length and a maximum cutting area of 220mm*570mm*160mm, it includes a rotary tool holder for products ranging from 0.3mm to 65mm in thickness. Perfectly suited for slicing and processing batches of hard and brittle materials into straight sheets.
This compact multi-line cutting machine is tailored for diamond line processing, offering options for single or double stations. It is engineered for small batch straight sheet processing, ensuring quick and effortless product specification changes. Capable of cutting sheet thicknesses from 0.5mm to 30mm, it provides both single and multi-line cutting functionalities, making it ideal for small batches of hard and brittle materials.
>Stable Wire Web Control
Ensuring unparalleled precision, the rollers, and wire spools utilize a cone-positioned structure, delivering exceptional accuracy and rigidity, effectively mitigating wire web shaking.
>Optimized Pulley System
Expertly engineered with 8 pulleys, this design effectively minimizes diamond wire torsion, significantly reduces tension fluctuations, and lowers the wire breakage rate, ensuring seamless operation.
>Easy Wire Winding
The wire pay-off wheel is equipped with the standard universal spool (PV600 reinforced I-wheel), which eliminates the need for wire rewinding, enhancing operational efficiency.
>Safety Guarantee
Experience heightened safety with the electrically operated main door, featuring an advanced safety device to ensure secure and reliable operation.
>Wire Break Memory System
>Easy Operation
Designed with user convenience in mind, the cutting room opens on three sides, ensuring effortless operation and maintenance, enhancing the overall user experience.
