0.42 Nm NEMA 17 (42 mm) Schritt Motor

Product Description

0.42 Nm 42mm (NEMA 17) Schrittmotor
Features:
High torque
Low noise
Smallsize Product Description:
1. Specifications:
Step Angle: 1.8°± 5% full step, no load
Shaft End Length: 141mm (5.55in)
Shaft: Screw Shaft, Customized Shaft Length
Connectors: Connectors, Lead Wires
Motor Length: 40mm (1.57in)
Holding Torque: 420mNm (59.47oz-in)
Rated Current: 1.0 A DC
Resistance per Phase: 6.7ohm
Inductance per Phase: 9.8mH
Ambient Temperature: -24ºC- +60ºC
Relative humidity: 90% MAX
Resistance Accuracy: ± 10%
Insulation Resistance: Larger than 100MΩ 500V DC
Dielectric Strength: 600V AC for 1S, leakage current less than 1mA
2. Note:
Performance and parameters can be customized, just simply send your motor diagram or samples to us, the competitive price will be sent to you soon for your reference.
Prices is decided by the motor's holding torque, Body length and other data, contact us and get the latest the price list.
3.Payment term:
T/T in advance, 30% deposit, 70% balance before shipment.

About Zhongshan Shengyang Motor Co., Ltd.: Zhongshan Shengyang Motor Co., Ltd., established in 2011, has anual production capability of more than 3 million pieces for stepper motor and micro motor. We passed ISO9001:2008 quality system, all products can be customized, welcome to contact us for more details.
Contacts: Ms. Rita Law
Mobile: (+86) 13631101993
shengyangmotor.en.made-in-china.com

Series & Length	Model Number	Holding Torque	Rated Current	Resistance per Phase	Inductance per Phase
		mNm oz-in	A	ohm	Mh
42BYGH0 26mm (1.02 in.)	42BYGH001	120 17	0.3	42	48
	42BYGH007	160 22.66	0.4	10.4	14
42BYGH1 33mm (1.30 in.)	42BYGH104	275 38.94	0.4	40	35
	42BYGH107	250 35.40	0.4	22	30
42BYGH2 34mm (1.34 in.)	42BYGH202	220 31.15	0.5	30	37
42BYGH3 40mm (1.57in)	42BYGH312	530 75.05	0.6	26	48
42BYGH4 40mm (1.57 in.)	42BYGH412	420 59.47	1	6.7	9.8
	42BYGH413	300 42.48	1	3.5	5
42BYGH11 34mm (1.34 in.)	42BYGH1101	240 33.98	0.4	30	45
	42BYGH1102	280 39.65	0.84	5.75	9.3
