Double Heads Saw Cutting Saw Machine for Aluminum Window Door Making Machine
| US$7,800.00-13,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
2GZXJS-500x4500
Condition
New
Certification
ISO, CE
Automatic Grade
Automatic
Voltage
380V
Cutting Motor Power
4.4kw
Air Pressure
0.6-0.8MPa
Cutting Angle
90-45 Degree
Weight
800kgs
Transport Package
Plywood Package
Specification
5530 1650 1550MM
Trademark
MAG
Origin
China
HS Code
84779000
Production Capacity
1000
Packaging & Delivery
Package Size
3000.00cm * 200.00cm * 190.00cm
Package Gross Weight
2000.000kg
Product Description
Product Description1). Used for cutting wide aluminum alloy profile and curtain wall profile , but also corner connector cutting;
can process two stations.
2). Pneumatic rotation and angle rotation at vertical 45° and 90°.
3). Pneumatic rotation and angle rotation at horizontal 45° and 90°.
4). Can manually set arbitrary angle within 45°~90°; horizontally; pneumatic rotation;
5). Single saw blade can operate independently;.
6). Manual measuring; equipped with measuring locking fine tuning appliance(optional digital display);
7). Saw hood can open and close safety protection independently;
8). Machine head connects with profile conveyor.
Product Parameters
| Brand Name | Mag |
| Power supply | 380V 50Hz |
| Input power | 2*2.2KW |
| Air pressure | 0.6-0.8 M pa |
| Main motor rotation speed: | 2800rpm. |
| Max/min Cutting length | 480-4500mm |
| Saw blade dimension: | φ450× φ30*4.4 |
| Cutting angle: | 90 ° ~45 ° |
| Cutting W X H | 240*135 ( mm ) |
| Repeat locating length | ≤0.2mm |
| Angle cutting tolerance | ±5′ |
| Plane of cutting surface | ≤0.10 |
| Cutting profile surface roughness | Ra12.5um |
| Size: (width X high X long) | 5750*1300*1500MM |
| Weight: | 1800Kg |
