Stepper Motor 1.8 Degrees Hybrid

Product Description

86HS1.8 degrees High Quality Stepper Motor
Specifications

Model	Number of phase	Current A	Rmductance Ω	Inductance mH	Holding Torque Nm	Rotor Inertia g-cm²	Detnt Torque mNm	Weight Kg	Length mm
86HS65-4560	2	5.6	0.6	3.5	3.3	1000	50	1.7	65
86HS65-8280	4	2.8	1.2	3.5	3.3
86HS76-4560	2	5.6	0.35	2.8	4.5	1400	140	2.2	76
86HS76-8280	4	2.8	0.7	2.8	4.5
86HS98-4600	2	6	0.43	4	6.5	1700	190	3	98
86HS98-8300	4	3	0.86	4	6.5
86HS114-4600	2	6	0.5	5.2	8.5	2700	230	3.6	114
86HS114-8300	4	3	1	5.2	8.5
86HS150-4600	2	6	0.72	8.2	12.2	3600	320	5	150
86HS150-8300	4	3	1.44	8.2	12.2

Note:
We only show several motor models, if these models are not what you want, please freely tell us about your requirement. We will provide you with a suitable motor solution and price soon.
FAQs:
1 Q: What's your MOQ ?
A: 1unit is acceptable.
2 Q: What about your warranty?
A: 1-2 years.
3 Q: Do you provide OEM service with customer-logo?
A: Yes, we could do OEM orders.
4 Q: How about your payment terms ?
A: TT, western union and paypal. 100% payment in advanced for orders less $10,000. 30% deposit and balance before delivery for orders over $10,000.
5 Q: How about your packing ?
A: Carton, Plywood case and foam inside. If you need more, we can pack all goods with pallet
6 Q: What information should be given in the inquiry?
A: Rated power, gearbox ratio, input speed, mounting position. More details, better!
7 Q: How do you deliver our order?
A: We will compare and choose the most suitable ways of delivery by sea, air or express courier.
We hope you will enjoy cooperating with us!
