Forestry Woodworking Machinery Wood Chipper Wood Recycling Crusher Machine

Product Description

Forestry Woodworking Machinery Wood Chipper Wood Recycling Crusher Machine
Company Profile
Product Description
Comprehensive wood crusher can be processed, pine, miscellaneous wood, Yang wood, fir, bamboo, because of the compact structure, small footprint, good chipping quality, low power consumption, and suitable for mobile operations widely used in small and medium-sized chipboard and fiberboard production enterprises of the material preparation section, can also be used for self-employed commercial wood chip production.
The main working principle of the Comprehensive Chipper is to put the material into the crushing chamber, and impact, break and shear the material through the high-speed rotating hammer or blade, so that the material becomes more finely broken.
From raw materials to finished products:
Detailed Photos

The material is fed into the crushing chamber of the crusher through the feeding port;
After the material enters the crushing chamber, it will be subjected to high-speed rotating hammer or blades.The impact and shear effects. The hammer or blade is driven by an electric motor and rotates at high speed rotate and collide with the material, shattering it.

The hammer or blade in the crushing chamber continuously impacts the material, causing it to be subjected to the impact and shear forces cause the material to break. The degree of fragmentation can be adjusted control the speed, quantity, and position of the hammer or blade.

After crushing, the material is sieved through the size of the sieve holes on the screen to achieve, after reaching the desired chips size, smaller chips pass through the sieve, while larger chips pass through continue crushing in the crushing chamber until the requirements are met.
Product characteristics:
1.Comprehensive crusher adopts high quality hammer, reduce downtime, high work efficiency
2. All accessories are carefully selected, excellent quality and durable
3. Pure copper motor, good performance, saving production costs for customers
4. Try a variety of materials, crushing effect is outstanding Product Parameters

Wood Chipper Model-Hammer Head Type
NO	Model	Power	Capacity	Hammer Head QTY	Inlet Size Width*Length*Height	Max Processing Diamater	Out Chips Size	Weight	Main Machine Machine Size
1	TPC1000	90KW	7-10TPH	16Pieces	1m*4.5m*45cm	2CM	25-55mm-Adjustable	9.8T	8100*1400*2125MM
2	TPC1000	110KW	8-10TPH	16Pieces	1m*4.5m*45cm	25CM	25-55mm-Adjustable	9.8T	8100*1800*2225MM
3	TPC1300-600	132KW	10-15TPH	24Pieces	1.3m*4.5m*60cm Chain Inlet	30CM	25-55mm-Adjustable	13.8T	9100*1900*2220MM
4	TPC1300-600	160KW	12-15TPH	24Pieces	1.3m*4.5m*60cm Chain Inlet	30CM	25-55mm-Adjustable	13.8T	9100*1900*2220MM
5	TPC1400-600	200KW	14-20TPH	24Pieces	1.4m*4.5m*60cm Chain Inlet	35CM	25-55mm-Adjustable	17.8T	10100*2400*2525MM
6	TPC1400-600	220KW	15-20TPH	24Pieces	1.4m*4.5m*60cm Chain Inlet	35CM	25-55mm-Adjustable	17.8T	10100*2400*2525MM
7	TPC1400-700	250KW	20-30TPH	24Pieces	1.4m*4.5m*70cm Chain Inlet	35CM	25-55mm-Adjustable	17.8T	11100*2400*2525MM
8	TPC1600-1000	315KW	25-35TPH	32Pieces	1.6m*4.5m*1m Chain Inlet	40CM	25-55mm-Adjustable	25.8T	12100*2400*2825MM
9	TPC1850-1000	355KW	30-40TPH	32Pieces	1.8m*4.5m*1m Chain Inlet	40CM	25-55mm-Adjustable	35.8T	13100*2500*2925MM
10	TONY8000	400KW	35-80TPH	28Pieces	1.8m*4.5m*1.2m Chain Inlet	55CM	25-55mm-Adjustable	55.8T	14100*2800*3125MM
11	TONY10000	630KW	50-100TPH	32Pieces	1.8m*4.5m*1.5m Chain Inlet	60CM	25-55mm-Adjustable	65.8T	15100*3000*3225MM

Packaging & Shipping
For the loose cargo we willpacking by wooden box
For the full container loadingwe are packing the machineby film and some on palletaccordingly
We can shipping the goodsby air or by sea
We will send pictures of cargoloading to our client to check and
roenrdinr
We can send cargo to client'swarehouse to loading
Machine use site:
The company has brought together a group of outstanding scientific research, production and management talents, creating a united, efficient and strict team. At present, the company's product sales have covered nearly the world, including: Russia, Japan, South Korea, France, Germany, Italy, Romania, Bulgaria, Malaysia, Vietnam, Thailand, Singapore, Cambodia, Indonesia, Iceland and many other countries and regions, well received by domestic and foreign users. We promise to let customers get the maximum benefit with the lowest investment!
After Sales Service

Certifications

FAQ:
1. Can you customize products for customers?
Yes, we can customize and produce crushing machinery according to customer's requirements or drawings.
2. How about the quality of your products?
After you receive the equipment, if there is a quality problem, our company will fulfill the responsibility according to the contract.
3. How can we trust your factory?
We recommend that you come to our factory to see the goods, verify the real situation of the products, and learn more about our factory.
4. Why do prices change so often?
The price depends on the latest prices of raw materials.
5. What's your minimum order quantity?
The minimum order quantity is 1 set. We shall appreciate your order.
We warmly welcome you to visit our factory at any time!
