Module spare parts ABB PM150V08 3BSE009598R1

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
ABB PM150V08 3BSE009598R1
Stand-Alone Mode: - this is the default operating mode after the start-up of DriveAP - the mode can be used without a drive - the following functions are available: - open a program file and display it graphically on the screen - modify the program on the screen - print the program on the screen - save the program on the screen to a disk file • Off-Line Mode: - the mode is started by menu command Connect - the following functions are available: - upload the program from the connected drive and display it - download the program on the screen to the connected drive - the functions of the Stand-Alone Mode • On-Line Mode: - the mode is started by menu command On-Line - all modifications to the program on the screen are automatically copied to the program in the connected drive - actual values of user-selected block pins are displayed on the screen in real time - the state of the time level in the drive (Running, Stopped or Edit) is displayed on the screen and can be changed by the user - the drive status information is displayed on the screen - values of non-AP parameters can be read from the drive and the user can change these values in the drive Operating Modes Introduction 1-6 DriveAP User’s Manual DriveAP User’s Manual 2 - 1 Chapter 2 – Installation of DriveAP DriveAP is designed to run under the Microsoft Windows 7, Windows Vista, Windows XP, Windows 2000 and Windows NT 4.0 operating environment on IBM-compatible PCs. Note: If you are using DDCS RUSB-02 adapter, do not insert the RUSB-02 adapter before you have installed the DriveAP software. Note: If you are using DDCS PCMCIA card, do not insert the PCMCIA card before you have installed the DriveAP software. Note: You must have Administrator privileges to your PC. Insert the DriveAP CD-ROM into the CD drive of your PC. Start the Control Panel program (Start->Settings->Control Panel) and double click its Add/Remove Programs icon. Click the Add New Programs button and follow the instructions that appear on the screen (select file Setup.exe from the CD-ROM). With Windows 7 and Windows Vista right click on setup.exe and select run as administrator. If you have the DriveWindow software in your PC and you want to use it at the same time with DriveAP, you must follow the instructions given in the DriveWindow User Manual (see its Chapter 10 – Advanced Information, Section 2.2 Several Clients). Now you can e.g. monitor graphically actual values of drive parameters while DriveAP is running. Note: Do not modify parameter values with DriveWindow (or panel) when DriveAP is in the On-Line Mode. Note: No DriveAP hardware is needed if you use only the StandAlone Mode of DriveAP.
