US$26.00-28.00
|
100 Pieces
(MOQ)
|
Basic Info.
Model NO.
KLT-M3MA-AR1335 PLCC V5.0
Specification
19.57 x 8.50 mm
Production Capacity
500000 Pieces
Product Description
13MP AR1335 PLCC MIPI-Schnittstelle Autofokus Kameramodul
Kameramodul Nr. KLT-M3MA-AR1335 PLCC V5.0
| Kameramodul Nr. | KLT-M3MA-AR1335 PLCC V5.0 |
| Auflösung | 13MP |
| Bildsensor | AR1335 PLCC |
| Sensorart | 1/3.2" |
| Pixel Größe | 1.1 um x 1.1 um |
| EFL | 3.81 mm |
| F.NO | 2.20 |
| Pixel | 4208 x 3120 |
| Betrachtungswinkel | 74.4°(DFOV) 62.7°(HFOV) 48.7°(VFOV) |
| Linsenabmessungen | 8.50 x 8.50 x 5.60 mm |
| Modulgröße | 19.57 x 8.50 mm |
| Modultyp | Autofokus |
| Schnittstelle | MIPI |
| Autofokus-VCM-Treiber-IC | FP5510 |
| Linsenmodell | KLT-LENS-50013A1 |
| Linsentyp | 650 nm IR-Schnitt |
| Betriebstemperatur | -30°C to +70°C |
| Gegenstecker | DF30FC-30DS-0.4V |
| KAI-47051 KAI-50140 KLI-2104 KLI-2113 KLI-8023 KLT Lens Kameramodul |
| LUPA300 LUPA1300-2 LUPA-3000 MANO9600 MT9D015 KLT Lens Kameramodul |
| MT9D115 MT9D131 MT9F002 MT9J003 MT9M001 KLT Lens Kameramodul |
| MT9M021 MT9M024 MT9M034 MT9M114 MT9M131 KLT Lens Kameramodul |
| MT9P001 MT9P006 MT9P031 MT9P401 MT9V022 KLT Lens Kameramodul |
