Plastic Egg Tray Package Thermoforming Machine

Product Description

Plastic Egg Tray Package Thermoforming Machine
Product Description
Multi-station thermoforming machine is a full automatic machine use PP, PET, PS to form platic trays, lids, containers, boxes. It combines forming, cutting, and stacking into process. This machine widely used and suitable for most of the customer
requested, is completely driven by servo motor. stable operation, low noise, high efficiency, high quality.
Product Parameters

Model	FSCT600/400-2	-3	-4
Max Forming area	600x400mm
Max Forming Depth and Height	80/40mm
Max Sheet Width	640mm
Max Sheet Roll Diameter	1100mm 1 Ton
Power	85kw	90kw	95kw
Dimension	7600x2100x2600mm	8200x2100x2600mm	9000x2100x2600mm
Weight	4T	5.5T	7T
Sheet Thickness	0.15-2mm
Max No-load Speed	35 Cycles/min

Features
1.Unwinding station electric lifting, double roll holder. allow for single operator loading rolls up to 1T
2. Fast and accurate temperature control system (error ± 1 degree), which can reach the set temperature in ten minutes
3. Quick front mold change, safe and simple die change, reducing machine downtime
4. Materials with strong shrinkage can adopt the single station die forming and punching function to 100% ensure the die edge cutting accuracy
5. High cost performance, low failure rate, abnormal alarm response mode, reducing the time cost of troubleshooting
6. Remote maintenance, instant judgment of obstacle messages, rapid correction and repair of problems
7. Integrated design of electric cabinet to simplify machine assembly and wiring installation proces
FAQ
Q1: Are you a factory or trading company? A1: We are a factory, and we has over than 20 years of manufacturing. Q2: How long is the warranty period?A2: 12 months warranty since the date of bill of loading.Q3: How to install the machine?A3: We will send technician to your factory to install the machine, and teach your workers to use it. You pay all related costs, including visa charge, double-way tickets, accommodation, meals, and technician salary.
