Low Cost Small Water Bottle Semi Automatic Blow Molding Machine with CE
| US$6,600.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JS-2II
Raw Material
PET
Making Method of Parison
Stretch Blow
Automation
Semi-Automatic
Computerized
Computerized
Certification
CE
Bottle Liter
0.2-2L
Machine Cavity
2
Machine Size (M)
1.62 X 0.67 X 1.68
Voltage
380V/50Hz
Clamping Force (Kn)
60
Hollow Part Volume
2L
Output (Kg/H)
1000
Power (Kw)
11
Weight (T)
0.58
Transport Package
Wooden Case
Specification
CE, SGS
Trademark
JS
Origin
Taizhou
HS Code
84773090
Production Capacity
400-850PCS/H
Product Description
200ml-2000ml Semi-Automatic Blow Moulding Machine bottle Making Stretch Blow Moulding MachineSemi-Automatic Blow Moulding Machine blow molding machine is suitable for producing PET plastic containers and bottles from 10-2000ml. It is widely used to produce the carbonated bottles, mineral water, pesticide bottles, oil bottles, cosmetic bottles, and wide-mouth bottles.
Adopting double crank to adjust mould, heavy locking mould, stable and fast, Adopt
Infrared oven to heat the perform, the perform rotated and heated equally.
The air system has been divided into two parts: Pneumatic action part and bottle
Blow part to meet the different requirements for the action and blow. It can provide
Sufficient and steady high pressure for blowing large irregular shaped bottles.
The machine is also equipped with muffler and oiling system to lubricate the mechanical part of the machine.
The machine can be operated in the step-by-step mode and the semi- auto mode.
The machine is small with low investment, easy and safe to operate by one person.
| Mold gathering strength (kN) | 60 |
| Mold traveling distance (mm) | 135 |
| Pulling rising traveling distance (mm) | 360 |
| Bottle spacing | 120-150 |
| Mold hole number (cavity) | 2 |
| Max. Bottle capacity (L) | 2 |
| Max. Tooth part size (mm) | 40 |
| Max. Bottle diameter (mm) | 95 |
| Max. Bottle body height (mm) | 360 |
| Theoretic production capacity (bph) | 700-900 |
| Total power consumption (kW) | 14 |
| Thermal rating (kW) | 12.8 |
| Operating pressure (kg/cm2) | 8 |
| Low pressure gas consumption (L/min) | 300 |
| Bottle blowing pressure (kg/cm2): | 25 |
| High-pressured gas consumption (L/min) | 350 |
Internal details of the Machine
