16000lbs Large Capacity Winch with ISO
Basic Info.
Model NO.
X16000
Pull Direction
Forward
Electric Winch Model
off Road
Working Voltage of Electric Winch
Low Voltage
Brand
Zhme
Applicable Environment
Mountain Road
Certification
GS, CE, RoHS
Product Name
Zhme Electric Winch
Rated Line Pull
16000lbs (7258kgs) Single Line
Motor
Series Wound 6.8HP /5.0kw, 12V DC
Gear Train
3 Stage Planetary
Gear Ratio
345: 1
Clutch
Sliding Ring Gear
Braking Action
Automatic in The Drum
Fairlead
Roller Fairlead for Wire Rope
Wire Rope
11.5mm*26m
Packing
700mmx300mmx400mm (300PCS Per 20′ Container)
Transport Package
1 Winch 1carton, 15cartons on 1 Pallet
Specification
N. W: 132lbs(62kgs)
Trademark
ZHME
Origin
Ningbo, China
HS Code
84253190
Production Capacity
10000 Sets/Month
Product Description
Features:1. High efficiency and energy saving motor.
2. New heavy-duty sealed contact with silver-alloy contact pads, being long life and high quality
3. Patent brake being more reliability and safety
4. O-ring sealed, protecting motor from water and dust
5. Aircraft grade wire rope, or synthetic rope is optional
6. Remote switch & wireless remote control being alternative
7. Using ENGO iron supports becoming stronger
Specification:
| Rated line pull: | 16000Lbs (7258kgs) single line | |||||
| Motor: | Series wound 6.8hp /5.0kw,12V DC | |||||
| Gear Train: | 3 stage planetary | |||||
| Gear ratio: | 345: 1 | |||||
| Clutch: | Sliding Ring gear | |||||
| Braking action: | Automatic in the drum | |||||
| Fairlead: | Roller fairlead for wire rope | |||||
| Wire rope: | 11.5mmX26m | |||||
| Drum size: | 3.5"×8.8"(88mm×224mm) | |||||
| Dimensions: | 23.9"×8.5"×9.4"( 608mm×216mm×239mm) | |||||
| Mounting bolt pattern: | 10"×4.5"(254mm×114.3mm) | |||||
| Battery: | Recommended 650 CCA minimum for winching 25 square mm,72"(1.83m) | |||||
| N.W: | 132lbs (60kgs) | |||||
| Packing: | 700mmx300mmx400mm (300pcs per 20' container) | |||||
| Line speed and motor current (first layer) | ||||||
| Line pull | Lbs | 0 | 2000 | 6000 | 12000 | 16000 |
| Kgs | 0 | 907 | 2722 | 5443 | 7258 | |
| Line speed | FPM | 19.7 | 12.5 | 8.2 | 6.2 | 4.3 |
| MPM | 6 | 3.8 | 2.5 | 1.9 | 1.3 | |
| Motor current | Amps | 70 | 120 | 200 | 290 | 420 |
| Line pull and cable capacity | ||||||
| Layer of cable | 1 | 2 | 3 | 4 | ||
| Rated line pull per layer | Lbs | 16000 | 14720 | 12580 | 9960 | |
| Kgs | 7258 | 6677 | 5706 | 4518 | ||
| Cable capacity per layer | Ft. | 17.6 | 37 | 63 | 85 | |
| M | 5.4 | 11.4 | 19.4 | 26 | ||
We can arrange you transportation, we have our own shipping and express company, or we can use your forwarder.
How to choose a ZHME Winch for your vehicle
Can't decide which winch is right for you? The best way to choose is to calculate the line pull needed for the application. To do this multiply your vehicle's Gross Vehicle Weight (GVW) by 1.5 - this will give an approximation for how big your winch should be. Typically, the first layer of rope around the drum is the max load the winch is capable of. Each additional layer deducts about 10% off the rated line pull. So for a winch rated 9,500lbs, the second layer will pull 8,550lbs, the third 7,700lbs, etc. A loss of pulling power can also be experienced when the rope isn't spooled evenly on the drum. So re-spool your winch before you go out!
