Z3050X16 Horizontal Universal Matal Hydraulic Clamping Radial Drilling Machine
Basic Info.
Model NO.
Z3050X16
Structure
Horizontal Drilling Machine
Layout
Horizontal
Controlling Mode
Artificial
Number of Shaft
0
Hole Diameter
<50mm
Automatic Grade
Manual
Precision
Normal Precision
Certification
CE
Condition
New
Motor
4000W
Main Technical Parameters
50mm
Base Working Face
300mm
Spindle Feed Range
0.04-3.2mm/Rpm
Transport Package
Wood Box
Specification
2500X1060X2800
Trademark
Jingren
Origin
China
HS Code
8459290000
Production Capacity
2000/Year
Product Description
Detailed PhotosProduct Parameters
| units | Z3050x16 | |
| Main technical parameters | mm | 50 |
| Distance from spindle center line to column bus | mm | 320-1220 |
| Distance between spindle center line and base working face | mm | 350-1600 |
| base working face | mm | 300 |
| Spindle taper hole (Mohs) | NO. | MT5 |
| Spindle speed range | rpm | 25-2000 |
| Spindle speed series | 16 | |
| Spindle feed range | mm/r | 0.04-3.2 |
| Spindle feed series | 16 | |
| lift motor power | Kw | 1.5 |
| power of main motor | Kw | 4 |
| Rotary Angle of rocker drill | 360° | |
| Machine weight | Kg | 3500 |
| Machine profile size (l X*W * H) | mm | 2500x1060x280 |
