Digital TV Front-End Integrated Receiver and Decoder Supports 4 Cass

Product Description

Multifunctional Streaming Processing Platform GM-8000S
The flagship stream processing equipment with high-speed IP-based digital TV front-end products. Together with IPQAM modulator, code stream receiving conversion and encoder with IP output. Traditional stream processing equipment and ASI to IP adapter and other equipment.
It constitutes a new generation of Gospel's new-generation digital TV front-end system based on IP and soft switching technology.
They will gradually replace traditional equipment and become the core equipment of our company's next-generation digital TV front-end system solution.
Main Features Full IP data processing, support MPTS and SPTS Supports multiplexing and scrambling of multiple program streams Supports the same secret and DVB-CSA scrambling Single device can complete all digital TV stream processing except code rate conversion and transcoding Data input and output network parameters can be flexibly configured Can process up to 500 input TS streams, 200 output TS streams, and 512 digital TV programs simultaneously TS input bandwidth reaches 1600Mbps and output bandwidth reaches 800Mbps Supports web-based network management without special network management software Automatically save user configuration to save last work status Multilingual device management page and related technical materials to adapt to domestic and international markets With working temperature and power supply monitoring function Dual power hot backup, seamless switching Support import and export of equipment working parameters All embedded software of the device can be upgraded online Technical Specifications

Input
Types	RJ-45
Input bit rate	≤1600Mbps
Format	MPEG TS-over-IP
	Unicast or multicast (IGMP 2.0 / 3.0)
Output
Types	RJ-45
Output bit rate	≤800Mbps
Format	MPEG TS-over-IP
	Unicast or multicast (IGMP 2.0 / 3.0)
Multiplexing Scrambling
multiplexing	PSI / SI tables support automatic generation or manual insertion
	Support intelligent program search
Scrambling	Support program-level scrambling
	Single TS scrambling code rate up to 60Mbps
	Built-in scrambler
	Support 4 CASs
EMM bandwidth	Maximum bandwidth 3Mbps
Bit rate statistics	Support TS stream, program, PID level real-time bit rate statistics
Max scrambled programs	512
Management
Interface type	Ethernet 10/100 Base-T
port	RJ-45
Power consumption
Input voltage range	85~260V AC
Input frequency range	50/60Hz
Power consumption	<15W
Environment
range of working temperature	5ºC~45ºC
Storage temperature range	-25~85ºC
Ambient humidity range	10%~90%
Physical index
Size (W x H x L)	483mm x 44mm x 450mm
Total Weight	5 Kg

Company Profile
Gospell was awarded "National Electronic Information Industry Model Enterprise" in 2013, and identified as "Famous Trademark" in 2014, also awarded "Hunan Province Governor Quality Award" in 2014, gained "Quality Credit Rating Certificate AAA" in 2015.
"High-frequency Microwave Copper-clad Plate Industry Model Enterprise" in 2015, "Beijing Science and Technology Award" in 2016, Gospell has a much higher brand influence in domestic and foreign markets.
FAQ
Q1: How to get a sample?
A: Sample order is acceptable. After price confirmation, you can require for samples to check our quality. If you need samples, we will charge for the sample and freight cost. The sample fee will be refunded if you place order.
Q2: What about the lead time?
A: In general, the lead time is about 25 to 35 days. But please confirm the exact delivery time with us as different products and different quantity will have different lead time.
Q3: How about the packing and shipping?
A3: Normally, we have carton for packing. If you have any other special requirements, please feel free to contact with us.
Q4: How about the OEM/ODM services?
A4 : We provide all kinds of OEM/ODM services ,
For example: Logo print on casing ,Customized packing, Software Customization. Please contact us to check the detail things before placing order.
Q5: How about the payment terms?
A5: We accept 30%T/T in advance, the 70% T/T balance before the delivery.
L/C, Money Gram and Western Union are also available.
Q6: How about warranty and procedure?
A6: Warranty time is 12 months. If you have any problem, please contact us in time, we will help you to resolve
the problem.
