Module spare parts T8110B

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

T8110B

SLS 1508 Logic Solver Physical Specifications Item Specifications Input Power 24 V DC ± 20%, 1.0 A plus field power (5.0 A total) Note: It is recommended that the SLS and DeltaV controller and I/O use separate power supplies Field Power 4 A maximum (actual value depends upon channel type and field device type) Isolation Each channel is optically isolated from the system and factory-tested to 1500 V DC. No channel-to-channel isolation. Local Bus Current None Mounting In SIS (yellow) terminal blocks in odd-numbered slots (1, 3, 5, 7) on the 8-wide carrier. Redundant SLSs take 4 slots. Logic Solver dimensions. SLS 1508 Logic Solver Weight, Heat Generation and Power Consumption Item Specifications Redundant Logic Solver Weight – 1.20 kg Heat Dissipation – 24 W Power – 2 A @ 24 V DC + Dig out Field Loads DeltaV SIS Logic Solver February 2021 /deltavsis 7 Channel Specifications The Logic Solver provides 16 channels of flexible I/O, meaning that each channel can be configured as an Analog Input (HART), HART Two-State Output, Discrete Input, or Discrete Output channel. Analog Input Channel Specifications (Includes Hart) Item Specifications Number of Channels 16 Isolation Each channel is optically isolated from the system and factory-tested to 1500 V DC. No channel-to-channel isolation. Nominal Signal Span 4 to 20 mA Full Signal Range 1 to 24 mA 2-Wire Transmitter Power 15.0 V minimum terminal-to-terminal @ 20 mA; current limited to 24 mA max Input measurement accuracy 0.2% of span Safety / Diagnostic Accuracy 2.0% of span Resolution 16 bits Filtering 2-pole, corner frequency 5.68 Hz -3 dB at 5.68 Hz -20.0 dB at 40 Hz (half the sample rate)
