Automatic 5 litres Bottle Water Bottling Plant
Product Description
Brief introduction :
This linear type automatic washing filling capping machine is suitable for all kinds of 3-10L bottle shapes (including the irregular-shape bottles). According to customer requirements, this machine can fill : such as: white wine, soy sauce,vinegar, spices, vegetable oil,Syrup, water and other liquid food products and pesticides and chemical industry, various types of liquid products.
This machine adopts computer (PLC) control, with high efficiency, precision measurement characteristics and is ideal packing machine for food, medicines, chemical products.

Machine picture:
Feeding bottle
Washing part
Filling part
Capping part
Cap loader
Whole bottle drying filling labeling line
Main technical data:

Model	LCGF4-4-1	LCGF8-8-3	LCGF10-10-3
Capacity (5L b/h)	500	800	1200
Filling volume(L)	3-10	3-10	3-10
Rinsing heads	4	8	10
Filling heads	4	8	10
Capping heads	1	3	3
Power(KW)	2.5	4.5	5.5
Dimension(mm)	3800×1100×1800	4500×1100×1800	5000×1100×1800
Weight(KG)	1000	1300	1600
