HC-G044 Bubble detector and pressure sensor infusion pump/Advanced Syringe pump

Product Description

Product Description
HC-G044 Bubble detector and pressure sensor infusion pump/Advanced Syringe pump
Product Description
Features for HC-G044 Bubble detector and pressure sensor infusion pump/Advanced Syringe pump:
1. HD LCD Display, high capacity words, friendly user interface, dynamically display working status;
2. Audible and visual alarm for occlusion, empty, low battery, end of infusion, door open, wrong setting, etc., which gain patents;
3. Compatible with any brands of infusion sets after correct calibration;
4. Preset solution volume to greatly reduce the workload of nurses;
5. Work mode: ml/h and drop/min can switch freely;
6. Three levels of occlusion: high, middle and low;
7. Purge function;
8. KVO (keep-vein-open) automatically opens as infusion is completed, KVO rate is 1-5ml/h(1ml/h step);
9. Power Source: AC100---240V, 50/60Hz; Internal Battery;
10. Automatically record the settings of last infusion;
11. OEM is available.
Specification of Infusion Pump

Rate	1ml/h ~ 1,200ml/h
Flow Rate Accuracy	Within ±5% (after correct calibration)
Mechanical precision	Within ±2%
Purge Rate	100ml/h ~ 1,000ml/h (100 ml/h step)
Infusion Volume	1ml ~ 9999ml
Total Infusion Volume	0.1ml ~ 9999.9ml
KVO rate	1ml/h ~ 5 ml/h (1ml/h step)
Occlusion	High: 800mmHg ±200mmHg (106.7kPa±26.7kPa Medium: 500mmHg ±100mmHg(66.7kPa±13.3kPa Low: 300mmHg ±100mmHg (40.7kPa±13.3kPa )
Unique audible and visible alarm	Human voice alarm for End of injection, occlusion, door open, bubbles in the tube, wrong setting, low battery, AC power pulled out etc.
Power Source	AC 100V ~ 240V, 50/60Hz; Internal rechargeable Li battery, capacity≥1,600mAh, 4 hours internal battery backup
Bubble detector	Ultrasonic wave detector; detection sensitivity ≥25μL
Fuse	F1AL/250V, 2 pc inside
Power Consumption	18VA
Operating Condition	Ambient temperature: +5℃ ~ +40℃; Relative humidity: 20 ~ 90% Atmospheric pressure: 86.0kpa ~ 106.0kpa
Transport & Storage Condition	Ambient temperature:-30℃ ~ +55℃ Relative humidity: ≤95%
Equipment Classification	Class II, internal power supply, Type CF
IP Classification	IPX4
Dimension	140mm (L) ×157mm(W) ×220mm(H)
Weight	1.8kg (net weight)

Pictures for HC-G044 Bubble detector and pressure sensor infusion pump/Advanced Syringe pump:
Other Hot sale Product in Happycare(Wall type K3 Measuring Instrument):
Packaging & Shipping
Company Information

Our Services
FAQ
1. How to place order of HC-G044B infusion warmer/Fluid Warmer/ blood warmer price ?
A: Firstly we confirm product details and then send the Proforma Invoice,
You make payment to us through Alibaba Trade Assurance or T/T, Western Union or MoneyGram,
after we confirm your payment then ship the product to you once finished production.
2. For infusion warmer/Fluid Warmer product,What’s the minimum order quantity (MOQ)?
A: For disposable material,We have our own MOQ,For our HC-G044B infusion warmer/Fluid Warmer/ blood warmer price , our MOQ:1pc,
3. What is your warranty?
A: For most products the warranty is for 12 months, some products we provide 18 months warranty.
For HC-G044B infusion warmer/Fluid Warmer/ blood warmer price , we provide 12 months warranty.
4. What’s your delivery time?
A: Generally it is 5 working days if goods in stock. within 10 working days if the goods need production,
And also the delivery time depands on quantity.For HC-G044B infusion warmer/Fluid Warmer/ blood warmer price , the delivery time is 10 working days.
5. How to ship the product?
A: The shipping way normally depand on your quantity,total CBM and weight.
We have our own shipping company to provide best shipping cost and efficient way.
