By800 Farming Tractor with Gasoline Engine Tracked Wheel
| US$3,500.00-5,200.00 | 3 Pieces (MOQ) |
Basic Info.
Model NO.
BY800
Bucket
Dragline
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Size
Medium-Sized
Certification
CE
Condition
New
Dimension
2170X900X1650mm
Rated Load
800kgs
Front Sholve
High Tip
Hydralic Piston Pump
Hydro-Gear
Color
Yellow Red Sliver Black
Package
Plywood Case
After-Sales Service Provided
Overseas Service Center Available
Transport Package
Plywood Case or Cartoon
Specification
CE
Trademark
ANT
Origin
Jiangsu, China
HS Code
84289090
Production Capacity
500unit/Month
Packaging & Delivery
Package Size
225.00cm * 90.00cm * 135.00cm
Package Gross Weight
715.000kg
Product Description
BY800 farming tractor with gasoline engine tracked wheel barrow electric farm tractorSpecifications
*Maximum loading weight is 800kgs.
*Easy and comfortable operation due to the intuitive controls.
*Self-loading shovel not only can be used as a small excavator but also keep the balance of the machine during unloading.
*Lifting height reaches to 1.4m by X-support.
*Easy climbing and stable crossing the obstacles.
*Spot turning, mini slipping.
Model
BY800
Engine
Honda GX390 13HP gasoline/B&S/Kama Diesel
Type
Hydra-static
Operative weight kgs(lbs)
800 (1762)
Max travel speed km/h(mph)
0-4.8(0-3.0)
Transmission
Hydraulic pump
2 x variable displ.
Flow Vmin(gpm)
2 x 32.4 (2 x 8.5)
Hydraulic motors
2 x orbital
Brake parking
Mechanical
Hydraulic system
Hydraulic pump
Gear pump
Flow Vmin(gpm)
1 x 13.5 (1 x 3.5)
Hi-flow Vmin(gpm)
1 x 22 (1 x 3.5)
Max pressure bar(psi)
150 (2180)
Main valve
2-3 way
Cooled system
Air-cooled
Skip tipping system
Hydraulic
Tracks
Standard track width mm(in)
180 (7.1)
Track roller
3
Rocking rollers
Yes
Track tensioning
Yes
| Model | BY800 |
| Engine | Honda GX390 13HP gasoline/B&S/Kama Diesel |
| Type | Hydra-static |
| Operative weight kgs(lbs) | 800 (1762) |
| Max travel speed km/h(mph) | 0-4.8(0-3.0) |
| Transmission | |
| Hydraulic pump | 2 x variable displ. |
| Flow Vmin(gpm) | 2 x 32.4 (2 x 8.5) |
| Hydraulic motors | 2 x orbital |
| Brake parking | Mechanical |
| Hydraulic system | |
| Hydraulic pump | Gear pump |
| Flow Vmin(gpm) | 1 x 13.5 (1 x 3.5) |
| Hi-flow Vmin(gpm) | 1 x 22 (1 x 3.5) |
| Max pressure bar(psi) | 150 (2180) |
| Main valve | 2-3 way |
| Cooled system | air-cooled |
| Skip tipping system | Hydraulic |
| Tracks | |
| Standard track width mm(in) | 180 (7.1) |
| Track roller | 3 |
| Rocking rollers | Yes |
| Track tensioning | Yes |
