Outdoor High Quality Big Die-Casting Aluminum Back-Cover Module 480X320mm P8 LED Display

Product Description

Outdoor High Quality fixed Big Module P8 LED display
Outdoor products are all waterproof and of high brightness!
Specification

Model		CN-FFH571	CN-FFH667	CN-FFH800	CN-FFH1000
Module	Pixel pitch	5.71mm	6.67mm	8mm	10mm
	Pixel density	30625dot/m2	22500dot/m2	15625dot/m2	10000dot/m2
	Pixel config	SMD2727(1R1G1B)	SMD2727(1R1G1B)	SMD2727(1R1G1B)	SMD2727(1R1G1B)
	Dimension	480×320 mm	480×320 mm	480×320 mm	480×320 mm
	Total Pixels	84*56 dot	72*48 dot	60*40 dot	48*32dot
Cabinet	Dimension	960*960*77mm	960*960*77mm	960*960*77mm	960*960*77mm
	Total Pixels	168*168dot	144*144dot	120*120dot	96*96dot
	Material	Aluminum
	Weight	28kg	28kg	28kg	28kg
Screen	Brightness	≥6500 cd/m2	≥6500 cd/m2	≥6500 cd/m2	≥6500 cd/m2
	View angle	HV 140/140	HV 140/140	HV 140/140	HV 140/140
	Best viewing distance	≥5Meters	≥5 Meters	≥5 Meters	≥5 Meters
	Colors of display	16.7M
	Refresh rate	≥3840Hz	≥3840Hz	≥3840Hz	≥3840Hz
	Gray scale	14Bit	14Bit	14Bit	14Bit
	Drive mode	1/7S	1/6S	1/4S	1/2S
	IP Index	IP65	IP65	IP65	IP65
	Max power consumption	650W/m2	650W/m2	650W/m2	600W/m2
	Average power consumption	220W/m2	220W/m2	220W/m2	200W/m2
	Input voltage	AC 100-240V,50-60HZ
	Control system	Nova
	Display function file formats	DVI,VGA,HDMI,HDSDI
	Operation temp	-20-65 ºC
	Operation Humidity	10-90% RH
	Application	Outdoor

the picture of real SMT workshop:

Q & A: 1. How can I place an order? Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with email /phone(Wechat is strongly recommended), in case of any delays. 2. What kind of display do we provide? We have indoor/outdoor/mobile LED /rental LED display /LED stage/ Advertising LED display /Transparent flexible film screen and so on. 3. What about the lead time for an order? Usually: 10-17 days, depending on your order quantity, sometimes we have stock, delivery within 7 days 4. What about the warranty? Two years!(the warranty of LED display industry practice is only 1 year)
Actually our products can run 5-10 years! 5. How about the quality? Our led products must be tested for at least 72 hours and make sure everything is perfect before shipping, from raw materials purchase to shipping. Each step has to pass the strict quality control systems to ensure the high quality of our products. 6. Can you offer a technical support? Since it's my first time.... We provide free training for our customer to set screens, broadcast the videos through Nova star and Colorlight control systems.
