Yuyun Sanhe Djf (b) -2 Series Double Mesh Hanging Ventilation Exhaust Fan Poultry Cow Chicken Farm House Poultry Farming Equipment
Basic Info.
Usage
Ventilation and Cooling Equipment
Application
Cow
Power Source
Electric
Certification
ISO9001:2008, CE
Condition
New
Warranty
2 Years
Frame Material
Galvanized Sheet
Zinc Coating
275g/Sqm
Blade Number
6
Drive
Belt Drive
Speed
1 Speed
Power Supply
Electric
Motor
Chinese Famous Xizi Motor
Voltage
380V/ 220V as Requirement
Frequency
50Hz/60Hz
Model
Ceiling Mounted Hanging Fan
Apply
Cow Cattle Dairy Farm Farming House Hanging Fan
Product Name
Double Mesh Hanging Ventilation Exhaust Fan
Transport Package
Standard Paper Carton
Specification
International standard
Trademark
Yuyun Sanhe
Origin
Shandong China
HS Code
8414809090
Production Capacity
500PCS/Day
Product Description
DJF(b)-2 Series Hanging Exhaust FanProduct Application:DJF(b)-2Series Hanging exhaust fan is widely used in the cow house for ventilation and cooling.
Technical Parameter:
| Model | Drive | Blades Diameter (mm) | Blades Rotational Speed | Motor Rotational Speed | Air Flow (m³/h) | Noise Decibels (db) | Input Power (W) | Voltage (V) | Frequency (HZ) | Outline Size (H*W*T) (mm) |
| DJF(b)-1-900 | Belt | 700 | 630rpm | 1400rpm | 22000 | ≤65 | 370 | 220 / 380/ Customized | 50 / 60 | 900*900*270 |
| DJF(b)-1-1000 | Belt | 900 | 610rpm | 1400rpm | 25000 | ≤70 | 750 | 1000*1000*270 | ||
| DJF(b)-1-1100 | Belt | 1000 | 600rpm | 1400rpm | 32500 | ≤70 | 750 | 1100*1100*270 | ||
| DJF(b)-1-1220 | Belt | 1100 | 460rpm | 1400rpm | 38000 | ≤70 | 750 | 1220*1220*270 | ||
| DJF(b)-1-1380 | Belt | 1270 | 439rpm | 1400rpm | 44000 | ≤70 | 1100 | 1380*1380*270 | ||
| DJF(b)-1-1530 | Belt | 1400 | 325rpm | 1400rpm | 55800 | ≤70 | 1500 | 1530*1530*270 |
Product Description:
| Fan blades 1. Material : 430 stainless steel, thickness 1.2mm 2. Diameter: 1270mm Advantage: Large air flow, no deformation, no fracture, no dust, attractive and durable. Note: Blade material also have galvanized sheet, aluminum alloy for option | |
| Belt Pulley 1. Material: High strength aluminum-magnesium alloy by die-casting. 2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability Advantage: Light weight, Low vibration ,attractive appearance. | |
| Safe Net Material: Hot-dip galvanized wire is coated with Plastic Advantage: Double Protection to ensure never rust. | |
| Hanging Rings Four hanging rings are added Advantage: Convenient to install and adjust the angle to reach excellent performance. | |
| Belt Brand: Mitsuboshi belt (Japanese) Type: A type Advantage: Famous brand, Long service life, maintenance free | |
| Round Frame Material: Hot-dip galvanized sheet with zinc thickness of 275g/sqm Advantage: Extremely improves the anti-corrosion performance. | |
| | Motor 1. Brand: Chinese famous motor, Siemens motor, ABB motor and WEG motor 2. Motor Protection Grade: IP55 3. Isulation Class: F grade Advantage: Motor voltage and frequency can be customized. Chinese famous motor OEM by special design for fan, the first put in the phase lack protection device which would power off when shortage of electricity. |
About our Company
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.
