constant tension control PVC, Pet, PE Film Laminating and Slitting Rewinding Machine

Product Description

Product Description
DP1300fq PVC, Pet, PE Film Laminating and Slitting Rewinding Machine
1300FQ PVC, PET, PE Film Laminating and Slitting Rewinding Machine
Feature:
This machine is slitting equipment of high precision and high sensitivity , with inflatable bearing used for feeding and receiving materials. Imported magnetic powder clutch is adopted to control the tension . Imported gas sensitive device is adopted to detect the rectification of rolling, with fully automatic hydraulic rectification control. Automatic detection,rectification and metering can be realized. It is characterized that accurate slitting , fast slitting speed, easy operation and maintenance, etc.
Purpose:
1. It is applicable for the slitting tooling of industrial adhesive tape, electronic material, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc.
2. This machine is widely used in the industries such as printing, packing, electronics, leather, clothes making, plastic, etc.
Main Technical Parameter:

Model	DP-1300FQ	DP-1600FQ
Max feeding Width	1300mm	1600mm
Main Engineer Power	6kw	6kw
Speed	80m/min	80m/min
Size	2400*2000*1300mm	2400*2300*1600mm
Weight	1200kg	1500kg
Unwinding Diameter	600mm	800mm
Winding Diameter	450mm	450mm
Precision	±0.1mm	±0.1mm
Power	380v 50hz	380v 50hz

Charatertistics and Functions:
1. This machine is slitting equipment of high precision and high sensitivity, with inflatable bearing used for feeding and receiving materials.
2. Imported magnetic powder clutch is adopted to control the tension.
3. Imported gas sensitive device is adopted to detect the rectification of rolling, with fully automatic hydraulic rectification control.
4. Automatic detection, rectification and metering can be realized.
5. It is characterized be accurate slitting, fast slitting speed, ease of operation and maintain
After-service:
1. Warranty for machine: 12months
2. After-service: A reply within 24 hours
3. A free training in our factory available before delivering machines.
1300FQ PVC, PET, PE Film Laminating and Slitting Rewinding Machine ----- Version
Application

Tefelon Tape PET film
