Premium 4mm PVDF Unbroken Aluminum Composite Panel for Versatile Applications

Product Description

Product DescriptionConstruction material Blue Aluminum Composite Panel ACP ACM
Aluminium composite panel is consisted of THREE layers, the surface and back covers of high strength aluminum alloy sheets and the core of nontoxic low density polyethylene (PE) sheet. The painting in the surface and back aluminum sheets are from PPG VALSPAR of USA and Becker of Sweden.

Second Name	Aluminium Composite Panel 4 mmm thickness
Aluminum Source	South West Aluminum Factory
Painting Source	PPG&BECKER
PE core Material	Non-toxic and low-density Polyethylene
Payment Term	TT, LC at sight
Production Capability	250000SQM/Month
More Service	OEM, Samples free(samples will be sent in one day time )
Feature	Super peeling strength/ Good temperature adaptability/ Excellent performance of fireproof/Weather proof/ Quickly installed/Excellent self-cleaning character

Features:1.Light weight, high strength, extreme rigidity; superior impact resistance,
2.Excellent surface flatness and smoothness ;
3.Heat insulation, sound insulation, fire-resistance;
4.Acid-resistance, alkali-resistance, good weather proofing and non-resonance;
5.Various uniform colors ,can be easily processed and fabricated, quickly installed;
6.Elegant and magnificent, good flexibility fits various designs;
7.Easily maintenance, simply cleaning.Specification:
Specifications Width: 1.22m; 1.25m; 1.5m; 2mLength: 2.44m; 3m; 5m; customizedSkin aluminum thickness: 0.06-0.5mmThickness: 2-6mmCoating: PE coating; PVDF coatingColor: Common; wooden; marble; mirror colors

Aluminium alloy	1100, 3003, 5005
Pencil hardness	2H
Toughness of coating	2T
Elongation	5%
Tensile strength	130 Mpa
Temperature Resistance	-50°C to +90°C
Impact Strength	50kg/cm2 , no change
Boiling water resistance	Boiling for 2 hrs, no change
Thermal Expansion	2.4mm/m at 100°C Temp difference
Acid Resistance	Immersed in 2% HC1 for 24 hrs, no change
Alkali Resistance	Immersed in 2% NaOH for 24 hrs, no change
Cleaning Resistance	Cleaned 1000 times with water, no change
Oil Resistance	Immersed in 20# engine oil for 24 hrs, no change
Solvent Resistance	Cleaned 100 times with dimethylbenzene, no change

Skyrainbow ACP Tolerance(mm)
Thickness	± 0.2
Width	± 2
Length	± 4
Diagonal	± 5

ApplicationApplications:1.Constructional exterior curtain walls;
2.Decorative renovation for store-added old buildings;
3.Indoors decoration for interior walls, ceilings, bathrooms, kitchens and balconies;
4.Gallaies,exhibition,saloons,stores,offices,banks,hotels,restaurants and apartments;
5.Advertisement board, display platforms and signboards;
6.Raw materials in industrial purpose;
7.Materials used for vehicle and boat.
Color Card
Packaging & ShippingPacking details:

Aluminum curtain wall material aluminum sandwich panel 1220*2440MM: packed in bulk or wooden pallet; If packed in bulk: 1638 sheets of 1220x2440x4mm can be loaded in a 20ft container; 2180 sheets of 1220x2440x3mm can be loaded in a 20ft container; 1312 sheets of 1220x2440x5mm can be loaded in a 20ft container. 1092 sheets of 1220x2440x6mm can be loaded in a 20ft container

Factory
Company Profile
FAQ* 1, Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer with 17 years experience in this field.
* 2, Q: How can i get the sample?
A: Small samples available are free, just freight collect.
* 3, Q: How long can I expect to get the sample?
A: We can prepare samples within 3 days. Usually it takes about 5-7 days for the delivery.
* 4, Q: What is your MOQ?
A: MOQ is 2 tons/order. Each size, thickness.
* 5, Q: What colors can you make?
A: The white color is most popular. And we can customize special color according to your requirement.
* 6, Q: Can we have our Logo or company name to be printed on your package?
A: Sure. Your Logo can be putted on the package by printing or sticker.
* 7, Q: What is your lead time for mass production?
A: Normally 15-30 days, depends on the size, quantity and season.
* 8, Q: What is your payment term?
A: T/T, L/C, D/P
* 9, Q: How do you pack it?
A: Each sheet covered by protection film, around 1.5 tons packed in a wood pallet.
