SGA40100AH/AHR/AHD horizontal surface grinding machines for metalwork

Product Description

Product Description
Fearures:
AH means: Auto intermittent feed on transverse, hydraulic transmission on longitudinal, manual on vertical.
AHR means: Auto intermittent feed on transverse, hydraulic transmission on longitudinal, rapid movement on vertical.
AHD means: Auto intermittent feed on transverse, hydraulic transmission on longitudinal, PLC auto grinding controller and servo motor is equipped and with wheel head auto down feed.

Model		Unit	SGA40100AH/AHR/AHD
Table size(WxL)		mm	406x1005
Max.longitudinal travel		mm	1130
Cross traval		mm	450
Max. distance from spindle center to table		mm	580
Magnetic chuck size		mm	400x1000
Speed of table longitudinal movement		m/min	7-23
Table transverse movement	Auto feed	mm/min	0.1-8
	Rapid speed	mm/min	990
	Feed of handwheel	mm/div.	0.02
Wheelhead vertical movement	Auto feed	mm/stroke	-(H/R mode) 0.005/0.01/0.02/0.03/0.04/0.05(0nly for D model)
	Rapid speed	mm/min	-(H mode) 610 (Only for R model)480 (Only for D model)
	Feed of handwheel	mm/div.	0.005
Grinding wheel	Speed	rpm	50Hz 1450
			60Hz 1750
	Size(ODxWxlD)	mm	350x40x127
Spindle Motor		kw	4/5.5
Hydranlic Motor		kw	2.2
Cooling pump motor		kw	0.09
Elevating Motor		kw	-(H mode) 0.25 (R mode) 0.5 (D mode,servo motor)
Cross feed motor		kw	0.06
Max.loading capacity of table(include magnetic chuck)		kg	600
Total rated power		kw	7.5/9
Gross weight		kg	3900
Package dimensions(LxWxH)		mm	3420x2250x2230
