Full Sexi Video Outdoor Screen P3/P4/P5/P6 P8/P10 Full Color Advertising LED Display

Product Description

Having HD display quality is one of the most important aspects for getting the attention of people passing by
your screen.Outdoor LED screens need to have clear resolution and high brightness to be visible in outdoor
environments.
It is necessary to have an LED screen with a brightness level that is higher than 5,000nits.This way,there is a
guarantee that the display will still be visible even under direct sunlight.
Another reason why outdoor LED screens deliver clear visuals is because of their high contrast rate.That makes
the images have a sharper look and vivid colors.
Take note,however,that screens with higher brightness tend to be a bit pricier.You must select the ones that
match your location.You do not want to pay for something that is not necessary.That's why it is highly
recommended that you talk to your LED screen supplier about what works for you.
Outdoor Full Color Display P3,P4,P5,P6,P8,P10 Product Parameters

Technical parameter	P3	P4	P5	P6	P8	P10
Dimension	192mm*192mm	320mm*160mm	320mm*160mm	192mm*192mm	320mm*160mm	320mm*160mm
Pixel pitch	3mm	4mm	5mm	6mm	8mm	10mm
Pixel Density	111111/ M2	62500/ M2	40000/ M2	27777/ M2	15625/ M2	10000/ M2
Pixel configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
LED specification	SMD1415	SMD1921	SMD1921	SMD3535	SMD3535	SMD3535
Pixel resolution	(W)64*64(H)	(W)80*40(H)	(W)64*32(H)	(W)32*32(H)	(W)40*20(H)	(W)32*16(H)
Average power	16W	16W	16W	16W	16W	12W
Panel current	6A	8A	8A	5-5.5A	8A	5.5A
Panel weight	0.41KG	0.45KG	0.45KG	0.38KG	0.49KG	0.44KG
Humidity	10%-95%RH	10%-95%RH	10%-95%RH	10%-95%RH	10%-95%RH	10%-95%RH
Number of unit boards per square meter	27PCS	19.5PCS	19.5PCS	27PCS	19.5PCS	19.5PCS
Hub connecting	HUB75	HUB75	HUB75	HUB75	HUB75	HUB75
Best viewing angle	Horizontal >170 Vertical>120	Horizontal >170 Vertical>120	Horizontal >170 Vertical>120	Horizontal >170 Vertical>120	Horizontal >170 Vertical>120	Horizontal >170 Vertical>120
Best viewing distance	3-10M	4--40M	5-60M	5-60M	5-60M	5-60M
Working temperature	-20-60	-20-60	-20-60	-20-60	-20-60	-20-60
Panel power supply	5V40A	5V40A	5V40A	5V40A	5V40A	5V40A
Screen power supply	220VAC/50HZ±10%	220VAC/50HZ±10%	220VAC/50HZ±10%	220VAC/50HZ±10%	220VAC/50HZ±10%	220VAC/50HZ±10%
Max power	<900W/m²	<1000W/M²	<1000W/m²	<1000W/ M2	<1000W/ M2	<800W/m²
Average power	350W	300W	300W	350W	300W	200W/m²
Power quantity	200W/5PCS	200W/4PCS	200W/4PCS	200W/6PCS	200W/4PCS	200W/6PCS
Driving device	16208 Constant current drive	16208 Constant current drive	16208 Constant current drive	16208 Constant current drive	16208 Constant current drive	16208 Constant current drive
Drive type	1/16S	1/10S	1/8S	1/4S	1/5S	1/4S
Refresh frequency	3840HZ/S	3840HZ/S	3840HZ/S	3840HZ/S	3840HZ/S	3840HZ/S
Display color	4096*4096*4096	4096*4096*4096	4096*4096*4096	4096*4096*4096	4096*4096*4096	4096*4096*4096
Brightness	5000cd/M2	5000cd/M2	5000cd/M2	6500cd/M2	5000cd/M2	5000cd/M2
Life span	100000Hours	100000Hours	100000Hours	100000Hours	100000Hours	100000Hours
Communication distance	<100M	<100M	<100M	<100M	<100M	<100M

P3 OUTDOOR LED MODULE
P4 Outdoor LED Module
P5 OUTDOOR LED MODULE
P6 LED MODULE
Weather Protection
When even a tiny amount of moisture or water gets inside your LED enclosure,it can damage your display
ermanently.The same goes for dust.
Outdoor LED screens have a special enclosure protecting them from rain and other liquid and solid infiltration.
Thus,an LED screen that you will install outdoors should be waterproof and dust proof. From an engineering
vocabulary,it is called Ingress Protection(IP).The IP determines the level of protection an outdoor LED has.
Atypical LED screen for outdoor use should have at least an IP65 rating.
So,when buying an outdoor LED screen,make sure to know the protection grade of the cabinet structure of
the screen.The Higher the IP rate,the better the protection it has against inclement weather.
The best outdoor LED screens are P2.5,P3,P4,P5,P6,P8,P10.But whatever matches your needs is
the one that you should go for,This article will help you choose the right outdoor LED screen that
will give the most benefits.
LED displays have become a vital element of making a successful advertisement.
Especially now that buyers and consumers are more drawn to digital displays than print sales materials.
However,for any digital advertising to be as effective as possible,you need to ensure excellent and
remarkable quality.
And when we say good quality,it does not only refer to the content of your marketing campaign.
Sound quality also pertains to the resolution and performance of the LED screen or billboard you will
use for your ad.
When reaching out to your target market,it is common knowledge that the message has to be clear,
enticing,and persuasive.It goes the same with the medium you will use to deliver your message.
It also has to be clear and enticing,looking to be convincing.
An ad content displayed on a poor-quality digital screen brings your business no good.And instead of
boosting your brand image,it may rather give you a bad reputation.
Aging test
Our Services
Niluo has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high
quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized
a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us
at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance
manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on
