20kg Automatic Silica Fume Valve Bag Bagging Machine
| US$7,600.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
BCS-50MI
Certification
ISO
Control Type
CNC
Power Supply
Electric
Automatic Grade
Semiautomatic
Shaft Type
Single
Layout
Vertical
Automation
Automatic
Condition
New
Processing
Dose, Filling
Product
Dry Mortar, Chemical Powder
Usage
Powder Packing
Capacity
5-7bags/Minute
Packing Range
10-50kg
Working Principle
Pneumatic
Transport Package
Woodbox
Specification
valve bag packer
Trademark
NW
Origin
Jiangsu
HS Code
8422303090
Production Capacity
200PCS/Year
Product Description
Valve bag packerBCS-50M automatic dosing valve bag packer is a new generation packer. It
has four patents: low air pressure pulse conveying, super wearable airfloating
device, automatic adjust double stroke gate valve, ceramic spout.
The packer is suitable for packing different type of raw materials. Such as industrial
micro-powder, powdery pigment, powdery chemical, flour and food additive,
all types of dry mortar and others.
Technical parameter:
Capacity: 6-7 bags/min( note: different material, the packing speed is different)
Precision level: ±0.5%
packing range: 10-50kg
Material inlet size: Φ300mm
Ceramic spout size: Φ63mm
Valve bag mouth size: ≥Φ70mm
Max. Aggregate granular size: 5mm
Working ambient: 0-40ºC, humidity≤90%RH, no dew
working power: AC220V/50HZ
Voltage fluctuation range: -15%~+10%
Frequency fluctuation range: ±2%
working air source: pressure≥0.5Mpa, air consumption is 0.2m3/min
Dust collection air volume:≥2000m3/h
Standard outline dimension: LXWXH=1500mmX650mmX1900mm
