Klt-USB-0485 V1 WiFi Camera 2.1MP 0485 Ar0230 M12 Fixed Focus USB 2.0 Camera Module
| US$55.00-60.00 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
KLT-USB-0485 V1
Application
Fixed Focus
Interface Type
USB
Transport Package
Anti-Static Bag in Box
Specification
38 x 38 mm / 32 x 32 mm
Trademark
KLT
Origin
China
Production Capacity
500000 Pieces
Product Description
2.1MP 0485 AR0230 M12 Fixed Focus USB 2.0 Camera ModuleCamera Module No. KLT-USB-0485 V1
| Camera Module No. | KLT-USB-0485 V1 |
| Resolution | 2.1MP |
| Image Sensor | AR0230 |
| Sensor Type | 1/2.7" |
| Pixel Size | 3.0 um x 3.0 um |
| EFL | 3.00 mm |
| F.NO | 2.40 |
| Pixel | 1920 x 1080 |
| View Angle | 96°(DFOV) |
| Lens Dimensions | 13.40 x 13.40 x 23.60 mm |
| Module Type | Fixed Focus |
| Lens Model | KLT-LENS-0485 V1 |
| Interface | USB 2.0 |
| Output Format | MJPG / YUV2 |
| Auto Control | Saturation, Contrast, Acutance White Balance, Exposure |
| Audio | Digital Microphone, Single, Dual Channel |
| Input Voltage | DC 5V |
| Working Current | Max 500mA |
| PCB Size | 38 x 38 mm / 32 x 32 mm |
| System Compatibility | Windows XP (SP2, SP3), Vista, 7, 8, 10, 11 Android, Mac OS, Linux or OS with UVC Driver Raspberry Pi by USB Port |
| Software for USB Camera | AMCAP, Webcam Viewer, V4L2 Controls Contacam, VLC Player, MotionEye OS iSpy, ZoneMider, Yawcam |
| Lens Type | 650nm IR Cut |
| Operating Temperature | -30°C to +85°C |
| USB Cable | KLT-Cable-U015 |
