1000kg Manual Glass/Window/MDF Boards/Sandwich Panels Heavy Duty Electric Vacuum/Suction up with CE ISO

Product Description

Specification (Support Customerized size)

Model	Length	Capacity	Sucker Qty	Sucker diameter	Input Voltage	Package Size	Gross weight
XDL300-2M	2m	300kg	4pcs	200mm	220/380V	2100x840x840mm	110kg
XDL600-2M	2m	600kg	6pcs	200mm	220/380V	2100x840x840mm	120kg
XDL800-2M	2m	800kg	8pcs	200mm	220/380V	2100x840x840mm	125kg
XDL800-3M	3m	800kg	8pcs	200mm	220/380V	2100x840x840mm	135kg
XDL1000-3M	3m	1000kg	10pcs	200mm	220/380V	2100x840x840mm	180kg
XDL1000-5M	5m	1000kg	10pcs	200mm	220/380V	2100x840x840mm	190kg
XDL2000-5M	5m	2000kg	20pcs	200mm	220/380V	2100x840x840mm	290kg

The vacuum suction cup crane is a fast, safe and convenient automated equipment. It uses the principle of vacuum adsorption, using a vacuum pump or vacuum blower as a vacuum source to generate a vacuum at the suction cup end, thereby firmly sucking up various workpieces, and transporting the workpieces to a designated location through a rotatable mechanical arm or crane.Used in factories, workshops, assembly lines and machine tools, warehouses, docks, etc.
Stainless steel machine tool feeding
Laser cutting machine loading
Mainly for semi-automatic loading of various types of laser cutting machines
A piece of machinery that can be used by one person to work efficiently
*Improve efficiency
*cost saving
*Reduce risk
*Simple operation
Equipped with electric cantilever loading
Evaluation of various equipment for different working scenarios.
There are retractable charging plugs and electric options to meet the needs of different working scenarios.

*Sheet metal welding for direct fastening, fully painted bracket connection, smooth joint, instant stability, not easy to break.
*Efficient supply and safe operation
Monitor vacuum pressure. When the vacuum pressure is too low, an audible and visual alarm will sound and effective supplementary pressure will be provided. When the pumping vacuum degree is lower than the specified value, an audible alarm will automatically sound.
*Suction cup can be sensed and adjustable to move the suction cup
Adjustable suction cup spreader, more flexible use scenarios
*the suction cups are made of imported rubber, which is durable and has a long service life.
*The square connection is fastened and the position can be adjusted freely to further improve convenience. The position of the suction cup combination is adjustable to meet jobs of different sizes.
* Suction Cup Buffer Each suction cup is equipped with a buffer device to effectively protect the vacuum system and workpiece.

*Vacuum control hand slide valve
A separate valve controls suction, release, and suction, and pulls back to turn off the suction.
*Anti-slip operating handle
High-quality material and unique design, considering the safety of customers when using, rubber wrapped, anti-slip to improve safety
1,Advanced safety protection device ,Vacuum automatic compensation system.
This system can not only automatically lock the air path, form a sealed environment, and continuously supply pressure, but also automatically detect whether the air pressure is sufficient; if insufficient air pressure occurs, the system will automatically operate to ensure sufficient vacuum for suction and lifting; compared to the market only The vacuum state is maintained by sealing the air path and the air pressure is manually adjusted. Automatic vacuum compensation greatly improves production safety and operational stability.
2, Intelligent alarm device
When the automatic detection system determines that the vacuum pressure is lower than the set value of 50, the vacuum alarm will sound and light and quickly replenish the supply (only 1.5 seconds). When the vacuum pressure is lower than the specified value, it will automatically sound the alarm.
3, 1 to 1 after-sales guidance and installation
If you don't understand something about the machine, we will provide you with full guidance to help you get started easily.
4, Machine warranty for one year
except for the wearing parts, the entire machine has a one-year warranty.
Package & Delivery
1, The factory has sufficient semi-finished products to meet the demand for quick delivery
2, Packed in sturdy export plywood wooden boxes to ensure the product is well protected during transportation
Safety Precautions
1, before the job must wear good labor insurance supplies, after training qualified before the job, the operator must go through special training before the operation.
2. Before lifting, check whether all parts of the sucker crane are firm and reliable, meet the use standards, and confirm that they are in good condition before they can be used.
3. There must be 8 symmetric suction cups for adsorbing items when the suction cups are hanging. Heavy operation is strictly prohibited to prevent injury accidents caused by falling due to non-tight suction.
4. When lifting, it is determined that the required pressure can be slowly lifted, and personnel are strictly prohibited from passing under the equipment. Personnel should stand at both ends of the material, hold the hand on the upper end of the material and keep a distance of more than 1 meter from the lifting object to prevent crowding injuries.
5. After the vacuum hoist is used, it should be shut down or unplug the power cord in time and put in the designated position.
6, the plate lifting process should have the operation area leader or appointed special person at the scene command.
7. Before lifting, check whether the sucker bolt is loose, whether the weld seam is cracked, and whether the body of the sling, the vacuum system and the sucker parts are abnormal. Before operation, check that the vacuum pump, hand slide valve, pressure relay, vacuum gauge, and rubber suction cup are free of foreign bodies, and that the pipes and joints are in good condition and free from leakage. After adjusting the length and width of the sucker frame, the top wire should be restored to the top tight position. Make sure it is intact before using the sucker. Should be inspected once a week, if there is damage, should be recorded. It can only be used when it is repaired or updated.
8. Check the vacuum system at least once per shift to see whether the rubber sucker falls off, whether the vacuum pump operates normally, whether the vacuum pump operates normally, whether the pipeline leaks, whether it is damaged, and if it is damaged, it should be updated.
9. Change the filter element every six months.
