One and Two Wire Braid R1 R2 1sn 2sn Hydraulic Rubber Hose

Product Description

One and Two Wire Braided Rubber Hydraulic Hose 1SN 2SN R1 R2
Our Advantages
Advantages
* Professional manufacturer for over 10 years in East China, near Shanghai and Ningbo port.
* Free hose sample.
* We can print words and your logo on the hose as your request.
* We test the products before shipping out. We have a complete line of test machines.
* We can also get you fittings or assembly.
* We ship the goods by express, by air, by sea or according to your requirement.
Product Description
Detail Information of Hose

Name	SAE 100R1AT/1SN
Material	NBR
Certification	CE approved.
Size	3/16"~2"
Color	Black
Temperature range	-40ºC~+100ºC
Reinforcement	One braid of high-tensile steel wire.
Surface	Cloth wrapped
Capability/Feature	Oil resistant, abrasion resistant, anti-aging.
Length	100m or 50m per roll.
Tolerance	0.05mm
Application	Medium pressure hydraulic applications including mobile, machine tool and agricultural applications, using petroleum or water-based hydraulic fluids.
Package	Well packed by poly stripes or as your requirement.
Delivery	According to your quantity, usually 35 or 40 days for a 20' container.

Part	In	Hose Size ID DIN Dash Size	Hose OD		Max. Working pressure		Min. Bend Radius		Min...Burst pressure		Weight (ibs/foot)
			In	mm	Psi	MPa	In	mm	Psi	MPa
GR1SN-03	3/16	4.8	0.47	11.9	3630	25	3.5	89	14520	100.1	0.12
GR1SN-04	1/4	6.4	0.534	13.6	3270	22.5	4	102	13080	90.2	0.15
GR1SN-05	5/16	7.9	0.595	15.1	3120	21.5	4.5	114	12480	86	0.17
GR1SN-06	3/8	9.5	0.689	17.5	2615	18	5	127	10460	72.1	0.22
GR1SN-08	1/2	12.7	0.813	20.7	2320	16	7	178	9280	64	0.28
GR1SN-10	5/8	15.9	0.938	23.8	1890	13	8	203	7560	52.1	0.33
GR1SN-12	3/4	19	1.096	27.8	1530	10.5	9.5	241	6120	42.2	0.41
GR1SN-16	1	25.4	1.408	35.8	1280	8.8	12	305	5120	35.3	0.62
GR1SN-20	11/4	31.8	1.696	43.1	920	6.3	16.5	419	3680	25.4	0.8368
GR1SN-24	11/2	38.1	1.971	50.1	730	5	20	508	2920	20.1	1.0921
GR1SN-32	2	50.8	2.503	63.6	580	4	25	635	2320	16	1.3413

Name	SAE 100R2AT/2SN
Material	NBR
Certification	CE approved.
Size	3/16"~2"
Color	Black
Temperature range	-40ºC~+100ºC
Reinforcement	Two braids of high-tensile steel wire.
Surface	Smooth wrapped
Capability/Feature	Oil resistant, abrasion resistant, anti-aging.
Length	100m or 50m per roll.
Tolerance	0.05mm
Application	High-pressure hydraulic oil lines used in construction, machine tool and agricultural applications using petroleum or water-based hydraulic fluids. Can also be used on CAT KOMATSU Excavator.
Package	Well packed by poly stripes or as your requirement.
Delivery	According to your quantity, usually 35 or 40 days for a 20' container.

Part	In	Hose Size ID DIN Dash Size	Hose OD		Max. Working Pressure	Min. Burst Pressure
			In	mm	MPa	MPa
GR2SN-03	3/16	4.8 DIN Dash size	0.484	12.3	41.4	165.5
GR2SN-04	1/4	6.4 DIN Dash size	0.593	15.1	40	160
GR2SN-05	5/16	8.0 DIN Dash size	0.649	16.5	35	140
GR2SN-06	3/8	9.5 DIN Dash size	0.753	19.1	33.1	132.4
GR2SN-08	1/2	12.7DIN Dash size	0.875	22.2	27.6	110.3
GR2SN-10	5/8	15.9 DIN Dash size	1	25.4	25	100.1
GR2SN-12	3/4	19 DIN Dash size	1.157	29.4	21.5	86
GR2SN-16	1	25.4 DIN Dash size	1.5	38.1	16.5	66.2
GR2SN-20	11/4	31.8 DIN Dash size	1.877	47.7	12.5	50.2
GR2SN-24	11/2	38.1 DIN Dash size	2.129	54.1	9	36.1
GR2SN-32	2	50.8 DIN Dash size	2.627	66.7	8	32

Workshop
We just imported 14 sets of brand new automatic inner hose knitting machines from Italy. The knitting speed is faster, production capacity has been greatly improved, quality is better and more stable.
Packaging & Shipping Packaging
Well packed by poly stripes or as your requirement.
Shipping
We ship the goods by express, by air, by sea or according to your requirement.

Testing and Certificates
Test Machines
In order to ensure the quality of our hydraulic hoses are good and stable. We test every batch of goods before sent out. Below are some common tests.
1 Working pressure test
All the hoses need to do this test before shipment.
2 Burst pressure test
3 Impulse test
1 wire and 2 wire braided hoses pass the impulse testing of 200,000 times; 4 wire spiral hoses pass the impulse testing of 400,000 times.
We also run other tests such as oil resistance test, ozone resistance test, aging test, etc. The test report can be provided.
Test Report Sample
Certification
Paishun has various types of certificates, such as ISO, CE, Rohs, MSHA, etc.
About Paishun About Paishun
Paishun factory covers a land of over 3 hectares, and the workshops occupy a surface of 25000 square meters. We own complete production lines of the rubber mixing process, cold feeding material extrusion process, microwave vulcanization process, and high-speed braiding process, etc.
We produce mainly the industrial hoses like Air Hose, Water Hose, Oil Hose, Welding Hose, Hydraulic Hose, and Assemblies. Paishun, being a rapidly growing enterprise focusing on the professional production of pure rubber hoses and braided rubber hoses, its yearly production capacity reaches 10 million meters.
Our key policy is "enterprise may thrive with the technology, and may last with good quality". So we put much investment in the research team, and in advanced testing laboratory equipment. We now use a series of tensile testing machine, vulcanization testing device, aging testing chest, pressure testing machines to ensure effective quality control. All these testing machines and related procedures may form a complete quality control system, beginning from the selection of the raw materials till the end step. Thus, we wish our products can satisfy in maximum our customers, and help them to gain more and more market share.
Paishun Team

Paishun Exhibition
Application
