Module spare parts　G122-824-002

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

G122-824-002

perating TEMPERATURE Module -20 to +70°C (-4 to +158°F) Termination Assembly - PVC -20 to +50°C (-4 to +122°F) RELATIVE HUMIDITY 5 to 95% (noncondensing) ALTITUDE -300 to +3,000 m (-1,000 to +10,000 ft) Storage TEMPERATURE -40 to +70°C (-40 to +158°F) RELATIVE HUMIDITY 5 to 95% (noncondensing) ALTITUDE -300 to +12,000 m (-1,000 to +40,000 ft) Contamination Suitable for use in Class G3 (Harsh) environments as defined in ISA Standard S71.04, based on exposure testing according to EIA Standard 364-65, Class III. Vibration 0.75 /S2 (5 to 500 Hz) PHYSICAL SPECIFICATIONS MODULE FBM212 mounts on a baseplate. The baseplate can be mounted on a DIN rail (horizontally or vertically), or horizontally on a 19-inch rack using a mounting kit. Refer to PSS 31H-2SBASEPLT for details. For applications which require CE certification, the baseplate and power supplies must be installed in a metal rack. Open wall mounting in that case is not allowed. TERMINATION ASSEMBLY The TA mounts on a DIN rail and accommodates multiple DIN rail styles including 32 mm (1.26 in) and 35 mm 1.38 in) Weight MODULE 284 g (10 oz) approximate TERMINATION ASSEMBLIES Compression 272 g (0.60 lb, approximate) Ring Lug 263 g (0.80 lb, approximate) Dimensions - Module HEIGHT 102 mm (4 in),114 mm (4.5 in) including mounting lugs WIDTH 45 mm (1.75 in) DEPTH 104 mm (4.11 in) Dimensions - Termination Assemblies Refer to page 8 Part Numbers FBM212 MODULE P0914XL TERMINATION ASSEMBLIES See “FUNCTIONAL SPECIFICATIONS - TERMINATION ASSEMBLIES” on page 7.
