Metal Bar Bending Machine and Metal Bar Forming Machine

Product Description

3D CNC Wire Bending Machine:
3D CNC wire bending machine is fully automatic and Servo driven, which is high efficiency and could save cost for customers from developed countries and high labor cost district. Application:
1. Auto Industry area
2. Metal wire industry
3. Furniture and Kitchen
4. Display table and cargo shelf
5. Hardware industry
6. Architecture area
7. Mattress,Sofa spring area
8.All kinds of high precision metal wire forming accessories industry
Machine Show: Mechanical properties:
1. The principle of swivel head wire bending machine is that the swivel head does not turn the line, the head structure is light, the head turns the line does not turn, to ensure the rapid and stable production operation.
2.The computer boot, shutdown speed is fast, easy to operate.Computer interface can be produced while speed control while changing the program.
3. High speed motor imported from Japan and speed reducer imported from Germany are adopted in the configuration, and the production speed is more than 25% higher than similar products of domestic counterparts.
4.Bearing, gear and other important parts imported from Taiwan parts, quality assurance 8760 hours, durable and reliable equipment.
5.High precision, can do 3.0mm-12.0mm line diameter range of wire forming products, error down to 0.1mm.
6. The computer operating system can be connected to the Internet to achieve remote control and operation.The production efficiency and output are displayed on the man-machine interface, and the equipment can stop automatically after reaching the specified output.
Details:
parameters:
Model No.:3D-12mm
No. of Axis :5Axis
Input OD of Wire :
Hard material Φ3.0~φ8.0mm
Soft material Φ4.0~φ10.0mm
Hard material Φ4.0~φ8.0mm
Soft materialΦ5.0 ~φ12.0mm
Group number of Wire feeding : 4 Group
Power of Wire Feeding Motor : 5.5KW
Power of Turning Motor :5.5KW
Power of Wire Cuter Motor :1.0KW
Power of Moving Motor :1.0KW
Power of Angle Control Motor : 2.0KW
Weight of Machine :3800KG
Input Power :380V/50HZ/3PH
Size of Machine : 3600mm X 1600mm X 2070mm
Our Advantages:
We produce and export all kinds of automatic wire bending machine. We also can design and
develop the wire bending machines according to your requirements. High precison and excellent performance for producing all kinds of springs and wire forms, Japanese Panasonic servo motor for each machine.
After order placed, we accept to adjust the products according to customer's demand, and remain
the program and tool settings on machine. in order to insure a quick start of machine once customer
receive it.
Samples:
The corner of the factory:
FAQ
Q1: What is the steel bar diameter your machine could deal with?
A1:3mm, 4mm, 5mm, 6mm, 7mm, 8mm,9mm,10mm,11mm,12mm, etc.
Q2: What is the power supply of machine?
A2: Generally it is 380V, 3PH, 50HZ.We can also customized accordingly.
Q3: What is the machine warrenty:
A3: 12 months.
Q4:What information should the customer provide to get an accurate quotation from us?
A4:The customer should provide the related technical requirements\drawings\pictures\industrial voltage\planned output,etc.
Q5:What is the delivery time ?
A5:Normally the delivery time of the wire bending machine is 30 working days after receiver down payment.
Q6:What is the payment term?
A6:The payment term is 30% down payment,and 70% before shipment(T/T),we also accept other payment term.
