Module spare parts 1C31166G02

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

1C31166G02

1. Set vent mode to A/C VC. 2. Use the quick key to set VT to 500 ml. 3. Select START VENTILATION > Continue. 4. Select Alarm Setup and set the VTexp high alarm limit to 700 and the VTexp low alarm limit to 600. The VTExp low alarm becomes active after three breaths. • Verify the medium priority VTexp low alarm sounds. • Verify the VTexp low alarm shows with a yellow background in the alarm bar. • Verify the display unit alarm light flashes yellow. 5. Select Alarm Setup and set the VTexp low alarm limit to 300. CARESCAPE™ R860 8-32 2065490-001 • Verify the VTexp low alarm no longer sounds. • Verify the VTexp low alarm shows with a grey background in the alarm bar. • Verify the display unit alarm light no longer flashes. VTexp high alarm test 1. Set vent mode to A/C VC. 2. Use the quick key to set VT to 500 ml. 3. Select START VENTILATION > Continue. 4. Select Alarm Setup and set the VTexp low alarm limit to 200 and the VTexp high alarm limit to 300. • Verify the medium priority VTexp high alarm sounds. • Verify the VTexp high alarm shows with a yellow background in the alarm bar. • Verify the display unit alarm light flashes yellow. 5. Select Alarm Setup and set the VTexp high alarm limit to 700. • Verify the VTexp high alarm no longer sounds. • Verify the VTexp high alarm shows with a grey background in the alarm bar. • Verify the display unit alarm light no longer flashes. Pmax alarm test 1. Set the vent mode to A/C VC. 2. Select START VENTILATION > Continue. 3. Select Alarm Setup and set the Pmax alarm limit less than the measured Ppeak. • Verify the high priority Ppeak high alarm sounds. • Verify the Ppeak high alarm shows with a red background in the alarm bar. • Verify the display unit alarm light flashes red. 4. Increase the Pmax alarm limit to remove the alarm condition. • Verify the Ppeak high alarm no longer sounds. • Verify the Ppeak high alarm shows with a grey background in the alarm bar. • Verify the display unit alarm light no longer flashes
