China High Quality and Good Price Lab Mixing Mill

Product Description

China high quality and good price lab mixing mill Product Description lab mixing mill is used to mix the raw material and additional agents uniformly for testing, and apply the experiment results and its ratio in the production line to satisfy the requirements of quality and color which specified by the customer. lab mixing mill is widely used in rubber, plastics industries. Such as polyolefin, PVC, film, coil, profile production and polymer blending, pigments, masterbatch, stabilizers, stabilizers and so on. The main purpose is to test raw materials's physical properties change and contrast after mixing. Such as color dispersion, light transmission, substance table.


Product Parameters

Lab Mixing Mill Model		-76	-120	-160	-200	-230	-300	-400
Diameter of roll	mm	76	120	160	200	230	300	400
Length of roller face	mm	300	350	350	500	650	650	900
Mixing Capacity	kg	0.002-0.6	0.002-2	0.002-2.8	0.002-5	0.005-10	1-15	5-30
Front roll surface speed	rpm	19	19	19	19	19	19	19
Friction ratio		1:1.30	1:1.35	1:1.35	1:1.35	1:1.27	1:1.27	1:1.27
Roll gap range	mm	0-3	0-6	0-6	0-8	0-12	0-12	0-15
Driving Power	KW	1	1.5	2.2	7.5	11	30	37
Heating Mode	Electricity heating , Oil Heating ( option)
Cooling Mode	Water Cooling ( option)
Roll Temperature	Room temperature -- 300ºC
Roll Hardness	HRC 50 ~ 60
Temperature Accuracy	± 2 ºC (we adopt the high accuracy PID micro computer controller)
Safety device	It have 6 safety buttons and safety guard is option
Machine weight	kg	160	460	660	860	1960	2960	3800
Overall dimension	mm	1100x400x1180	1100x550x1380	1200x650x1380	2200x750x1380	2200x950x1580	2600x950x1580	5295x1789 x170
Power	380V 3 phase 50-60hz

Detailed Photos
lab mixing mill Feature:
1. Construction of mill rolls: drilled roll, bored roll, grooved roll
2. We can design speed ratio as per customers' formula and processing requirements.
3. Frame, frame cap and base are welded and treated by annealing for stress relieving.
4. Rolls material is chilled cast alloy iron which hardness is reach to 70HB.
5. Brake and emergency stop device can ensure the safety of personnel and equipment.
6. Auto feeding oil or grease lubrication, it is easy to maintain and protect machine
7. Human nature designed controlling system ensure labor safety.
8. Methods of adjusting roll nip: manual or electric
After Sales Service 1.we will one year guarantee for the machine . During this period if there is anything wrong with machine , supplier are responsible for it and should offer the best spare part freely for buyer 2.supplier should send professional if required by customer 3.we will offer service for whole life of machine
