Three Axies 250CNC Versatile Surface Grinding Polishing Machine Tool Design

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
At Cheng Yu Machinery Technology Co., Ltd., we are committed to a philosophy of relentless enhancement across all our offerings. We maintain the right to revise specifications, mechanics, or designs without prior notice or obligation, ensuring our products evolve with innovation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd. was founded in Dongguan City, Guangdong Province, extending 30 years of Taiwanese expertise in grinding machine manufacturing. A wealth of experience and technological prowess is embodied by our dedicated team of technical professionals. The rapid evolution of CNC machine tools is ushering in new eras of high-speed, precision, and multi-functional capabilities. The trajectory is towards intelligent, open, and networked systems with green environmental consciousness as core tenets. Dongguan Chengyu Machinery Technology Co., Ltd. excels in the specialized production and processing of machine tools and accessories. We adhere to a 'technology, innovation, reliable' ethos, with an unwavering 'meticulous' quality policy. Our mission is to deliver superior products that serve our customers' precise needs. By understanding client processes, technology, and production requirements, we continuously refine our products for optimal applicability. As we expand in the CNC industry, we prioritize high automation, precision, and quality, supported by an outstanding quality management system, premier equipment, and expert craftsmanship. Chengyu Machinery meets market demands by designing and manufacturing high-precision CNC surface grinding machines, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We also specialize in the creation of industrial robots, automated production lines, and integrated applications. Below is a concise overview of our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (available in servo and hydraulic types) Processing capabilities include surface grinding and grooving. Features a patented hydraulic control system (hydraulic type). Functions include advanced grinding programs for flat surfaces and groove cutting. Feed mode options are flexible: front, back, left, or right. Each grinding program retains the memory of its feed mode. Automatic shutdown is triggered by grinding wheel overload. II. Available in servo and hydraulic types Processing capabilities include surface grinding, grooving, and complex scheduling. Incorporates a patented hydraulic control system (hydraulic type). Equipped with diversified grinding programs: surface, groove, sole, side grinding, and unique displacement grinding. Grinding wheel dressing: Bottom plane dressing with automatic dressing and compensation based on pre-set rough/fine grinding schedules. Selectable feed modes (front, back, left, right) with memory retention for each grinding program. Features equidistant and non-equidistant grooving with unequal depths. 3. The four-axis CNC grinding machines are available in horizontal and vertical configurations. Processes include arbitrary equal divisions and complex skipping tooth processing. For waist circle processing, input size AB. For triangle fillet operations, input inscribed circle size B and fillet size R. For quadrilateral fillet, input side lengths A and B, and fillet size R. For eccentric circles, input eccentricity along with starting and ending diameters. For circles, simply input the starting and ending diameters. Arc: Simply input the desired arc size and rotation angle to achieve precision and perfection. Step Difference & Rotation Profile: Effortlessly manage step differences and rotation profiles for exceptional accuracy. Processing Schedule: Save your processing schedule as a file for seamless recall and efficient future operations.
