Tough 19-Inch Rugged Industrial Panel PC with High-Performance Capabilities

Tough 19-Inch Rugged Industrial Panel PC with High-Performance Capabilities

US$330.00-900.00 1 Piece (MOQ)

Basic Info.

Model NO.
SC19W
Certification
FCC, ROHS, CE
Stylus Support
Yes
Battery life
None
Voice Assistant
No
Special Features
Waterproof
CPU Core
Dual-Core
CPU Type
Intel Core I5-8250u
Drive interface
Usb 3.0
Charging Interface
DC
Battery Capacity
No battery
Hard Disk Capacity
≥128G
Memory
8g
Network Mode
WiFi
Operating System
Windows
Card Reader
Without Card Reader
Built-in Bluetooth
Built-in Bluetooth
Built-in Microphone
Without Microphone
Fingerprint
Without Fingerprint
Display Resolution
1280*1024
Screen Size
19"
Screen Type
Capacitive Screen
Rear Camera Pixel
None
Front Camera Pixel
None
Webcam
Without Webcam
Storage
128GB
IP Grade
Full IP67 Waterproof
Temperature Range
-20 to 70 Celsius
Warranty
1 Years Warranty
Certificate
CE, FCC, RoHS
Installation
Wall-Mounted
Power Supply Type
Adapter
Rack Unit
All in One
Transport Package
Carton
Specification
66x47x18cm
Trademark
Sihovision
Origin
China
HS Code
8471414000
Production Capacity
5000piece/Month

Product Description

Introducing the robust and resilient High-Performance 19-Inch Stainless Steel Touchscreen PC, expertly crafted for the most demanding environments. This powerhouse of technology promises unparalleled durability and exceptional performance.
Main Products
Feedback
Product Description
Features:
1. Constructed from high-grade stainless steel SS304, this panel PC offers full IP67 waterproof protection with specially designed waterproof connectors, ensuring optimal performance even in harsh conditions.
2. Equipped with a superior 19'' industrial LCD panel, it boasts a wide viewing angle and an impressive 1000 nits brightness, making it perfectly readable under direct sunlight.
3. Utilizing advanced 5-wire resistive touch screen technology, this device guarantees high precision and durability. It effectively resists interference and supports touch functionality with gloves and water presence.
4. Exhibiting unparalleled resistance to acid, alkali, and corrosion, this PC is also designed with anti-glare features for optimal visibility in any environment.
5. The screen features optical bonding, seamlessly integrating the LCD and touch screen to enhance clarity and reduce reflection.
5. Ingeniously designed with waterproof rubber seals between the front frame and rear shell, it can be effortlessly disassembled for inspection and maintenance without compromising its waterproof capabilities.
6. Powered by a high-performance motherboard, this panel PC is engineered for relentless 24/7 operation, ensuring reliability and continuous functionality.
Specification
PC
CPU Intel® Core, i3-1115G4, Dual Core , Quad Threads, Base 1.7 GHz, Turbo 4.1 GHz, Fanless
Other CPU Optional
Chipset SOC
Memory 1*SO-DIMM DDR4 3200MHz Max32GB
Hard Drive Capacity 1 * M.2 (NGFF) Key-M Slot (PCIe x4 NVMe SSD, 2242/2280), 1 * Mini PCI-E Slot (mSATA, SATA3.0), 1 * SATA3.0 7P Connector (with 1 * SATA Power Header)
Graphics Intel® Iris® Xe Graphics
Audio Audio Codec
1 * Front Audio Header (Line-Out + MIC)
1 * Line-Out + MIC 2in1 3.5mm Jack (default CTIA, OMTP Standard SEL by res)
2 * Amplifier, 5-W (per channel) into an 8-Ω Loads
Network Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)
Wireless Network WIFI, Bluetooth, 4G, GPS Optional
Operation System Support Windows 7/8/10, Linux, Ubuntu, Debian etc.
External I/O Ports
USB 2x IP67 USB2.0
LAN 1x IP67 RJ45
COM 1x IP67 RS232
Power input 1x IP67 9-36V DC
Other 1x IP67 Power on/off button, 1x IP67 Breather valve ,
LCD panel
Panel size 19"
Display active area 376.32(W)x301.056(H) mm / 14.816x11.853 in
Resolution 1280*1024
Aspect ratio 5:4
Brightness (cd/m²) 1000 nits sunlight readable
Brightness control PWM software to adjust brightness
Contrast ratio 900:1
View angle 85°/80°/80°/85° (R/L/U/D)
Support color 16.7M
Backlight WLED, 50K hours
Touch panel
Touchscreen Type 5 wire resistive touch
Surface Hardness 3H
Surface treatment Anti glare
Luminousness ≥90%
Touch controller IC EETI ETR400
Available touch drivers Windows, Linux, Android, Mac
Touch bonding Optical bonding (Air bonding Optional)
Touch optional 10 Points capacitive touch, IR touch, Non touch optional
Power Supply
Working voltage 12V DC (9-36V DC Optional)
Power consumption 65W
Power adapter AC 100 ~ 240V input and DC +12V@7.5A MAX output, 90W
Enclosure
Material Stainless Steel 304
Finish Wire drawing
Color Silver
Mounting VESA mount 75x75/100x100mm
IP rating Full panel IP67 waterproof
Cooling system Passive - Fanless
Operating Environment
Temperature Range Operating: -20 to 70°C, storage :-30 to 80°C
Relative humidity Up to 100% at all relevant temperatures, non-condensing
Vibration GB/T 2423.10-2019
Shock GB2423.5
EMC Class B
Packing Details
Product weight Net weight 8.49kg
Product dimension 453×378×65mm
Packing info 1pc/ctn 66×47×18cm 12kg
2pcs/ctn 67×48×34cm 25kg
Accessories Power adapter, Power plug, Waterproof LAN cable, Waterproof USB cable*2
Other
Warranty 1 year warranty
Certificates CE, FCC, RoHS
Customized
Certifications
Company Profile
FAQ
Sihovision is strategically based in China to support global marketing efforts. We are actively seeking long-term partnerships with local distributors. Contact us today to learn more!
