Efficient Professional Device for High-Precision Solar Battery Cutting

Product Description

Equipment Use: Introducing an advanced, state-of-the-art solution designed to significantly enhance customer cutting efficiency and precision. Boasting an impressive roller length of 690mm and a versatile table size of 170/145mm*690mm*160mm*2, this cutting-edge device is meticulously crafted to manage product thicknesses from a delicate 0.3mm to a robust 65mm. Its adaptability assures unrivaled precision and flexibility across a multitude of applications, setting a new standard for excellence.
CHTXQ-690F Double Plate Multi-Wire Cutting Machine - Key Product Features
1. Independent Drive: Embrace the future of innovation with our four independently driven motors, where each roller functions uniquely as a drive shaft. This forward-thinking design substantially reduces steel line wear, greatly extending the lifespan of the rollers. With expertly engineered mounting holes on each roller bracket, the spindle's installation achieves perfect coaxial precision, thanks to cutting-edge processing center molding techniques.
2. LED Display Option: Enhance your operational prowess with our sophisticated LED display, which provides crystal-clear, intuitive cutting data. This state-of-the-art feature transforms user interaction, making operations smoother and more insightful than ever before.
3. User-Friendly Design: Revolutionize your workflow with our innovative under-table design, which redefines the loading and unloading process. Materials are effortlessly cut from the bottom up, granting operators unparalleled ease and efficiency in their tasks.
4. Versatile Models: Choose from our expertly crafted high-speed and standard models, each engineered to meet diverse needs. The high-speed variant boosts performance with increased line speeds, substantially enhancing cutting efficiency. By supporting the use of finer diamond lines, it elevates precision and productivity to new heights.
5. Flexibility in Motion: Experience the freedom of motion with the table's transverse movement capability, allowing it to glide effortlessly back and forth. This ingenious feature enables precise tile cutting and offers the versatility of single-line cutting functionality, tailored to your specific requirements.
6. Enhanced Loading Area: Our machine's generous loading area, measuring 170/145mm*690mm*160mm*2, is designed to optimize overall cutting efficiency. This meticulous design accommodates larger capacities, streamlining workflows and significantly elevating productivity levels.
7. Precision and Stability: Our unwavering commitment to precision is evident with a spindle accuracy of ≤0.01mm, complemented by a patented dust structure (Patent No. ZL201320681902.7). This ensures stable operation and facilitates effortless disassembly for maintenance, guaranteeing long-term reliability and peace of mind.
8. Effortless Operation: Simplify your operational demands with a machine equipped with an automatic lifting shield and a fully expandable workbench. This user-centric design makes loading and unloading materials and rolls seamlessly effortless, allowing you to concentrate solely on maximizing productivity.

	unit	parameter
Maximum Worksize	mm	170/145*690*160*2
cutting thickness	mm	0.6~65
running speed	m/min	0~2200
Table lift stroke	mm	220
Table cutting feed speed	mm/hour	0.1~100
The amount of wire output from the supply wheel	Km	30(φ0.2diamond wire)
Diamond diameter	mm	φ0.06~φ0.35axle
Roller outside diameter*number of axles	mm	φ155/φ180*690*4
boundary dimension	mm	≈1830*2800*2650
machine weight	Kg	6500~115000
power		AC380V/50HZ three-phase four-wire
Total machine power rating	Kw	54 above

Experience unparalleled innovation with our double-station multi-wire cutting machine, utilizing diamond wire technology for extraordinary precision. It efficiently processes products with simultaneous dual plate capability, offering a roller length of 690mm and a maximum cutting area of 220mm*690mm*160mm*2. The versatile rotary tool holder function expertly manages cutting blade thicknesses from 0.5mm to 65mm, excelling in both single-line and multi-line cutting for hard and brittle material batch processing.
Step into the forefront of cutting technology with our multi-line cutting machine, employing state-of-the-art diamond line technology. With a roller length of 570mm, it provides a maximum cutting area of 220mm*570mm*160mm. The adaptive rotary tool holder function skillfully handles product thicknesses from 0.3mm to 65mm, making it ideal for slicing hard and brittle materials in batch straight sheet processing.
Our compact multi-line cutting machine is the epitome of efficiency, featuring advanced diamond line technology and available in both single and double station models. Tailored for small batch straight sheet processing, it offers seamless specification changes, expertly handling sheet thicknesses of 0.5mm to 30mm. Supporting both single-line and multi-line cutting, it is the perfect solution for small batch processing of hard and brittle materials.
Yutian Changtong Eiectron Co., Ltd. has been a beacon of technological evolution since 1998, originally known as Yutian Changtong Electronics Factory. The pivotal transition in 2007 elevated it to Yutian Changtong Electronics Co., LTD. Celebrated for pioneering breakthroughs, the company was distinguished as a high-tech entity in Hebei Province by 2001 and achieved the prestigious national high-tech enterprise status in 2016. This evolution included the establishment of a dynamic branch in Yantai, Shandong Province, in 2006. Today, Yutian Changtong stands as a national high-tech titan, masterfully conducting a seamless integration of research and development, production, sales, and service, all in exquisite harmony.
Product Introduction
Main Products: Delve into our vibrant array of innovative products, featuring cutting-edge quartz crystal chips (frequency sheets), premium green silicon carbide powders, advanced multi-line cutting machines, and sophisticated electronic mechanical equipment, each engineered to redefine the horizons of innovation.
Quality Certification
Rooted in the empowering belief that technology fuels productivity, Yutian Changtong Eiectron Co., Ltd. has flourished through strategic alliances with esteemed academic and research institutions, including Northeastern University, Yantai University, Hebei University, Dongguan University of Technology, Beijing Institute of Printing Machinery, and the prestigious Chinese Academy of Sciences (units 203, 45, 707, 607). These esteemed partnerships have propelled significant advancements, resulting in multiple patents, with one illustrious patent showcased in the distinguished National Science and Technology Database.
Yutian Changtong Eiectron Co., Ltd. is a beacon of excellence, honored as a 'High-Tech Enterprise of Hebei Province'. The company has garnered numerous prestigious accolades, including 'Small and Medium-Sized Enterprises of Science and Technology in Hebei Province', the coveted 'National High-Tech Enterprise' title, and recognition as a 'Specialized and Special New Enterprise'. Enhancing its esteemed stature, the company is celebrated as a 'Municipal Enterprise Technology Center', 'Municipal Industrial Design Center', and a highly respected 'National 3A Credit Enterprise'. These accolades underscore our unwavering dedication to innovation and our relentless commitment to delivering exceptional industry excellence.
Value Concept
Guided by unwavering principles of 'Ethical, Integrity Management', Yutian Changtong Eiectron Co., Ltd. consistently earns recognition as an exemplary A-level tax entity across provinces, cities, and counties. Our steadfast dedication to honesty and quality garners the distinguished titles of 'Honest Enterprise', 'Quality and Credit Enterprise', and 'Outstanding Builders of Socialist Undertakings with Chinese Characteristics'. These esteemed honors stand as testaments to our unyielding commitment to integrity and unmatched quality across every facet of our operations.
