1500mm Precision Manual Lathe Machine Horizontal Lathe Machine for Metal Cutting

Product Description

√ Experience the epitome of durability and precision with our Cost-Effective Horizontal Lathe Machine's guide way, embodying an extraordinary hardness beyond HRC52°. This remarkable feat is achieved through the meticulous application of a high-precision CNC guide way grinding machine, ensuring both unparalleled longevity and astounding accuracy in every cut.
√ The lathe's head box, feed box, and sliding box are the epitome of precision craftsmanship. Each of these components is flawlessly crafted using advanced CNC machine center techniques, ensuring that every piece meets the pinnacle of machining precision and excellence standards.
√ Revel in the whisper-quiet operation of our transmission gear, engineered to perfection with meticulous CNC gear grinding and exhaustive noise testing. This assures not only a smooth and seamless operation but also a serene and productive work environment.
1. Quenched Guideway
The quenched guide rail is the hallmark of extraordinary hardness and wear resistance, delivering unmatched durability and performance in every application.
2. Tool Post
Enhance your lathe's versatility with the standard 4-position tool post, or opt for the optional quick-change tool post for even greater operational flexibility.
3. Three-Jaw Chuck
Equipped with a standard 3-jaw manual chuck, you can also choose the adaptable 4-jaw chuck option to expand your machining capabilities and possibilities.
4. Tailstock
Perfectly designed with a standard manual tailstock, this feature is ideal for efficiently managing shaft bar workpieces, enhancing productivity.
5. Working Light
Incorporates a working light to elevate operator convenience, ensuring ease of operation in every task.
1500MM Precision Manual Lathe Machine Horizontal Lathe Machine for Metal Cutting

Model			CN6240
Max swing over bed		mm	420
Center height		mm	210
Max work piece length		mm	1000, 1500, 2000, 3000
Bed rail width		mm	390
Max turning diameter of work piece on tool holder		mm	220
Max turning diameter of workpiece in saddle groove		mm	630
Valid length of gap		mm	240
Through hole diameter		mm	82
Bore hole		mm	90/1:2
Spindle rotation speed		rpm	9-1600
Max transverse travel of tool rest		mm	320
Max travel of small tool rest		mm	145
Distance between spindle center line and tool support surface		mm	about 28
Tool cross sectional dimension (H*W)		mm	25*25
Longitudinal feed		mm/r	0.028-6.43
Transverse feed		mm/r	0.028-6.43
Taper of center sleeve inner hole		mm	MT5
Max movement of center sleeve		mm	150
Max transverse movement		mm	±15
Thread	Inch system		72-1/8t/in
	Metric system		0.5-224
	Module		0.5-112
	Diameter pitch		56-1/4DP
Motor specification			7.5kw 1500rpm
Belt specification			B-2260
Dimension (L*W*H)	1000mm	mm	2625*1043*1275
	1500mm	mm	3125*1043*1275
	2000mm	mm	3625*1043*1275
	3000mm	mm	4800*1043*1275
	3500mm	mm
