Aluminium Aluminum Flat Bus Bar & Square/Rectangle Bars (6061/6063/6082/6101)

Product Description

Aluminum Flat Busbars Bus Bars (6061/6063/6082/6101)
The most common form of bus conductor is bar stock of rectangular cross section. This shape is inherently easy to fabricate, store, handle and erect. A relatively large surface area can be provided for the dissipation of heat by the use of multiple-bar buses. Joints and taps are readily made by either bolting or welding. Off-sets and 90-degree bends are easily made.
For direct current, as well as for alternating current up to certain limits, the capacity of a bus constructed of flat bar can be controlled by merely varying the size of bars or number of bars in parallel. For high-amperage alternating current, however, special arrangements of laminations are used .
Packaging Details:
Delivery Detail: 2 - 3 weeks ( depends on quantity )
Place of Origin: Zhengzhou, China (Mainland)
Brand Name: Chalco
Model Number: AL1070
Material: Aluminum
Product Name: Customized Aluminum Busbar
Surface Treatment: Zinc, Nickel, Tin, Silver, etc.
Tolerance: +/- 0.1mm
Length: up to 6m
Width: 10mm - 200mm
Thickness: 0.15mm - 40mm
Application: Electric
Processing: Stamping, Bending, Drilling, Threading, Polishing, etc.
Typical Applications
• Heat exchanger tubing • Electrical conductors • Medical and chemical equipment
• Pharmaceutical containers • Cable sheathing • Food handling equipment
Chemical Composition

Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others		Al.
								Individual	Total
Max. 0.20	Max. 0.25	Max. 0.04	Max. 0.03	Max. 0.03	-	Max. 0.04	Max. 0.03	Max. 0.03	-	Min. 99.70

Properties
Aluminium and Copper Specifications

Parameters	Aluminium	Copper
Relevant Standards	IEC 60105 ISO 209-1,2	IEC 60028
Physical Properties Chemical Composition Specific Heat gm.cal/ºC Density gm/cm2 Melting Point ºC	0.092 2.91 660	99% pure 0.220 8.89 1083
Mechanical Properties Ultimate Tensile Strength kgf/mm2 Ultimate Shearing Strength kgf/mm2 Elastic Modulus kgf/mm2 0.2% Tensile-proof Strength kgf/mm2	20.5/25 15 6,700 16.5/22	22-26 16-19 12000 60-80% of tensile strength
Electrical Properties Specific Resistance cm Volume Conductivity mm2 Conductivity % IACS Co-efficient of expansion mm/m/ºC	3.133 31.9 57 2.3*10-5	1.7241 58 100 1.73*10-5

Rectangular angle aluminium busbar
3mm (thickness)	3*15	3*20	3*25	3*30	3*40	3*50
4mm (thickness)	4*10	4*20	4*25	4*30	4*40	4*45	4*50
5mm (thickness)	5*20	5*25	5*30	5*35	5*40	5*50	5*60	5*80
6mm (thickness)	6*20	6*30	6*40	6*50	6*60	6*80	6*100	6.3*50	6.3*80	★6.3*100
7mm (thickness)	7.6*80								6.3*76	★6.3*63
8mm (thickness)	8*11	8*30	8*40	8*50	8*60	★ 8*63	8*80	8*100	8*120	8.1*74
10mm (thickness)	10*30	10*40	10*50	10*60	★10*63	10*80	10*100	10*120	10*125	10*140
	10*150	10*160
12mm (thickness)	★12*60	★12*80	★12*100	12*120	★ 12*125	12*150	★ 12.5*125
14mm (thickness)	★14*80	★14*100		Square rod	★ 50*50	★ 35*55	19*19	Six angle rod	★30	★40
15mm (thickness)	15*100	15*120		Round rod	★¢10	★¢12	¢16	★¢28	★¢32	★¢40
16mm (thickness)	★16*100	★16*125		Round rod	★¢45	★¢46	★¢50	★¢55	★¢60	★¢65
20mm (thickness)	★20*80	★20*100			★¢70	★¢75	★¢80

Round angle aluminium busbar
2mm (thickness)	R2*20
3mm (thickness)	R3*30	R3*40	R3*50	R3*60	R3*80	R3*100	R3*120	R3*160
4mm (thickness)	R4*25	R4*30	R4*40	R4*50	R4.7*151
5mm (thickness)	R5*30	R5*35	R5*40	R5*50	R5*60	R5*120
6mm (thickness)	R6*50	R6*60	R6*80	★R6.3*63	R6*100	R6*120	R6*140	R6*160
8mm (thickness)	R8*40	R8*50	R8*60	★R8*63	R8*80	R8*100
10mm (thickness)	R10*50	R10*60	R10*80	R10*100	★R10*120	R10*125	R10*170	R10.4*25
12.5mm (thickness)	★R12.5*80	★R12.5*125		★R16*120

Features:
Metal Mate aluminium flat bar is lightweight and easy to work with, available in various widths and lengths.
All profiles are in mill finish;
Used in brackets, supports, wear strips, buffers, skirting boards, repair and maintenance around the home.
Lightweight and easy to work with;
Can be bent into various shapes;
Easy to drill, rivet and screw.
