Lty-4000 Servo-Type Plastic Injection Molding Machine
| US$55,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
LTY-4000
Type
Plastic Product Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrap Film Packing Into The Container
Specification
400T
Trademark
LOYALTY
Origin
China
HS Code
8477101090
Production Capacity
1000sets/Years
Product Description
| Specification Table | LTY4000 | |||||
| A | B | C | D | |||
| Injection Unit | Screw Diameter (mm) | 65 | 70 | 75 | 80 | |
| Screw L/D Ratio (L/D) | 23.7 | 22 | 20.5 | 19.3 | ||
| Shot Size(Theoretical) (cm³) | 1220 | 1428 | 1639 | 1819 | ||
| Injection Weight ( g) | 1050 | 1258 | 1359 | 1665 | ||
| Injection Rate (g/s) | 315 | 357 | 406 | 440 | ||
| Plasticizing Capacity (g/s) | 40 | 50 | 60 | 78 | ||
| Injection Pressure (Mpa) | 208 | 180 | 156 | 138 | ||
| Screw Speed (rpm) | 4000 | |||||
| Clamping Unit | Clamping Force (KN) | 150 | ||||
| Toggle Stroke ( mm) | 700 | |||||
| Space Between Tie-Bars (mm) | 730*730 | |||||
| Max.Mould Height (mm) | 850 | |||||
| Min. Mould Height (mm) | 280 | |||||
| Ejector Stroke (mm) | 180 | |||||
| Ejector Tonnage (KN) | 126 | |||||
| Other | Max.Pump Pressure (Mpa) | 16 | ||||
| Pump Motor Power (KW) | 37 | |||||
| Heating Power (KW) | 23.5 | |||||
| Machine Dimensions(LxWxH) (m) | 8.1*2.1*2.9 | |||||
| Machine Weight(Approximate ) (t ) | 17 | |||||
