Low Price Cut to Length Machine with Steel Coil

Product Description

Are you looking for a high-quality cross-cutting line with outstanding performance?
In the field of shearing equipment, compared with other types of cross-cutting machine production lines, the biggest advantage of the TENGDI brand cross-cutting machine production line lies in its cutting accuracy and speed. Its cutting accuracy reaches ±0.15mm, and its fastest cutting The speed reaches 100m/min, so it can greatly improve the production efficiency and ensure the quality of shearing. TENGDI cross-cutting machine production line integrates energy saving, high efficiency and stability, and has been widely used in automobile manufacturing, home appliances, hardware, metallurgy and other manufacturing industries.
Product Description

Material	HR,Q235,Q345,Q510,special steel etc.	Coil ID	Φ508-Φ760
Length arrarge	1000-2000	Coil OD	≤Φ1500
Coil max weight	≤35T	Length range	1000-12000
Power	~255kw	Diagoral tolerance	≤±1.5
Speed	≤16m/min	Flatness	≤2.0
Thickness	3.0-12mm	Floor space	50×10m

Technical Parameters

Type	3×1600	6×2000	8×2000	10×2200	12×2200	16×2200	20×2500	25×2500
Thickness Range(mm)	0.3-3	1-6	2-8	2-10	3-12	4-16	6-20	8-25
Width Range(mm)	1600	2000	2000	2200	2200	2200	2500	2500
Cutting Length(mm)	300-4000	500-6000	600-8000	600-10000	800-12000	800-12000	800-12000	800-12000
Cutting precision(mm)	±0.5	±0.5	±1	±1	±1	±1	±1	±1
Roller Numbers	15	15	13	13	11	11	9	9
Roller Diameter(mm)	Ф85	Ф140	Ф155	Ф160	Ф180	Ф200	Ф230	Ф260

Flow chart and product unit

Packaging & Shipping
Processing capacity
Exhibition photos
Certifications
FAQ
Q: Are you manufacturer?
A: Yes. We are manufacturer. We have our own technical team. Welcome to visit us.

Q: What payment terms do you accept?
A: We are flexible on payment terms, please contact us for details!

Q: What info you need before you make the proposal?
A: The pipe diameter and thickness range which you need or the profile drawings material information, your special requirements and speed of the machine.

Q: How do you do QA?
A: We have special team do strict QA, this is our strengths:
(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.
(2)Every shaft will be inspected for the centering jumpiness.
(3)Every roller will be checked to make sure it is in the range of tolerance critical parts will be inspected for all dimensions.

Q: Why choose you? What is the difference between you and other Chinese supplier?
A: You can get higher quality product & better professional service from TENGDI with same price.
