Fully Continuous Waste Tyre Pyrolysis Plant with EU Emission Standard
| US$45.00-47.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
XFLJ-15
Certification
CE, ISO
Voltage
380V
Structure
Horizontal
Product Name
Fully Continuous Waste Tyre Pyrolysis Plant with E
Keyword
Waste Tyre Pyrolysis Plant
Capacity
15, 30t/24h
Working Temperature
650 Centigrade
Heat Way
Hot Air Circulation
Tyre Size Request
Less Than 50 mm
Working Pressure
Normal Pressure
Inflaming Retarding Way
Nitrogen Blowing
Start up Fuel Comsumption
300-400 Kg Hfo
Power
110 Kw/H
Transport Package
Sea-Worthy
Specification
14000x2250x3750 mm
Trademark
Honest
Origin
Qingdao, Shangdong
HS Code
8477800000
Production Capacity
50 Sets/Year
Product Description
Product Description Fully continuous waste tyre and plastic pyrolysis plant adopts automatic feeding and discharge system, Q345 boiler steel plate as material for rotated reactor. Oil output can reach 50%. Capacity from 15T to 100T. Aftercouple of hours, Syn gas from pyrolysis generated and burn to supply energy to support the pyrolysis procedure by hot air system. Pyrolysis oil cleaned in gas treatment system and then inserted to oil distillation system, which can make it be clean diesel and petrol. Carbon black and steel wire will be separated and collected at the end of the system. This is the most advanced technology, energy saving and environmental friendly.
Plant Specification
| Item | Type | XFLJ--SL-15 | XFLJ--SL-30 |
| Capacity/24h | 15T | 30T | |
| Working temp. | ≤650° | ||
| Fuel | Fuel oil, natural gas, lpg | ||
| Heating way | Hot air circulation heating | ||
| Fuel request | Waste plastic, medical waste and household waste | ||
| Working pressure | Normal pressure | ||
| Inflaming retarding way | Nitrogen purging | ||
| Consumption | 200 kg | 200 kg | |
| Size | 14000 × 2400 × 4000(mm) | 28000 × 2400 × 4000(mm)×2 | |
| Total power | 90 kw | 170 kw | |
| Power consumption | 80 kw/h | 150 kw/h | |
| Floor space | 40000 mm × 4000 mm | 40000 mm × 9000 mm | |
| Highest point of installation | 7000 mm | 7000 mm | |
