Poultry Livestock Feed Making Dry and Wet Straw Corn Hay Cutter Home Use Best Quality Chaff Cutter

Product Description

Poultry Livestock Feed Making Dry and Wet Straw Corn Hay Cutter Home Use Best Quality Chaff Cutter
Product Description
1. The oversize product is 3.8-15 tons/hour. The cutting length is adjustable, which can cut wet and dry grass, and the yield is stable and high.
2. Suitable for all grasses, such as corn stalk, straw, radish, potato, sweet potato, cassava, etc.
3. Wheels at the bottom, easy to move. This machine is small and light. Save labor and time, simple operation and long service life.
4. Cutting grass, shredding, crushing, corn, automatic feeding, and dual use of diesel and electricity.
5. Thicken the plate, widen and enlarge the feed inlet, galvanize the chain bars, and increase the cutter head with silicon alloy blades.
6. Give away tools for free
7. Exported to more than 30 countries and regions
Product Parameters
More Models for your Choose :
Hay cutter:

Model	Output capacity	Power(kw)	Weight (kg)	Wooden Packing Size(mm)	Inlet size
9ZR-380	3800kg/h	4KW	90	1470×500×830	40-52mm
9ZR-450	4500kg/h	4.5-5.5KW	100	1680×500×880	42-58mm
9ZR-480	4800kg/h	4.5-5.5KW	125	1780×530×930	42-58mm
9ZR-550	5500kg/h	5.5KW	130	1780×560×980	44-61mm
9ZR-580	5800kg/h	7.5KW	160	2130×600×980	48-65mm
9ZR-680	6800kg/h	7.5-11KW	200	2200×610×990	48-65mm
9ZR-800	8000kg/h	11KW	230	2450×750×1050	57-75mm

Cutting and grinding powder integrated machine:

Model	Output capacity	Power(kw)	Weight (kg)	Wooden Packing Size(mm)	Inlet size
ZRF-4.0	4.0t/h	4.5-5.5KW	150	1900×530×840	38-51mm
ZRF-5.0	5.0t/h	5.5KW	170	2100×530×870	43-59mm
ZRF-6.0	6.0t/h	7.5KW	190	2450×580×980	46-63mm
ZRF-8.0	8.0t/h	11KW	230	2450×580×980	46-63mm

High Spray Hay Cutter:

Model	9Z-1.2	9Z-2.5A	9Z-4.5A	9Z-6.5A	9Z-8A	9Z-10A/15A
Supporting power	3kw	3kw	5.5w	7.5-11kw	11kw	15-18.5kw
Motor rated speed	2800rmp	2800rmp	1440rpm	1440rpm	1440rpm	1440rpm
Machine output	1200kg/h	2500kg/h	4500kg/h	6500kg/h	8000kg/h	10000kg/h
Number of blades	6	6	4	3/4	3	3/4
Number of flail knife	18	18	16-20	9/12	15	15-24
Dimensions	880*1010*1750 MM	1050*1180*1600 MM	1750*1420*2380 MM	2147*1600*2735 MM	2350*1890*3090 MM	2630*2500*4100 MM
Discharge length	7-35MM	7-35MM	10-35MM	10-45MM	10-35MM	10-35MM
Feeding method	Hand feeding	Automatic feeding
Structure type	Disc type	Guillotine kneading	Disc type	Guillotine kneading	Disc type	Disc type
Machine weight (excluding motor)	80KG	125KG	300KG	400KG	550KG	950KG

Raw materials and uses
Detailed Photos
Safe operation and maintenance:
1. The supporting power must meet the requirements and it is not allowed to increase the spindle speed without authorization.
2. Before starting the machine; Check if the running direction of the machine is the same as the hoe cutting direction, otherwise it is strictly prohibited to start the machine.
3. Materials that need to be hoed and cut must not be mixed with hard objects such as metal and stones, otherwise it may cause damage to the machine.
4. After a few hours of machine operation, it is necessary to observe whether each component is loose and regularly add grease to the bearings.
5. When feeding materials, the operator's hand is strictly prohibited from approaching the blade to avoid personal injury accidents. The feeding should be evenly and in moderation, not too much or too little, fast and slow.
6. During work, if grass blockage or other faults are found, the power should be immediately turned off and the fault should be eliminated before starting the operation. It is strictly prohibited to operate the machine with faults.
7. Non staff members and those who are not familiar with the performance of the machine's mechanism are not allowed to start the machine casually.
8. When the machine is not in use for a long time, it should be stored indoors or in a shed to prevent rusting.
