Rubber Floor Tile Hydraulic Vulcanizing Press Vulcanizer Machine

Product Description

Hydraulic Press Machine for Rubber Tile
I. characteristic
1. Light specific gravity;
2. No powder particles clean adsorption;
3. Stretch and good elasticity;
4. Particles and strong PU glue adhesive performance not easy threshing;
5. Wear-resisting not easy ageing, keep clean as new;
6. Good weather resistance, small production process affected by temperature, can be all-weather use.
II. Technical paramenter

Model	XLB140T	XLB50T	XLB25T
Nominal clamping mould force	1400KN	400KN	250KN
Max working-oil pressure	20	16	16
Hot plate size	1200*1200	600*600	500*500
Hot plate space	400	150	150
Working layers	1	4	4
Max plunger stroke	400	600	500
Heating mode	Steam/eletric heating	Steam/eletric heating	Steam/eletric heating
Hot plate pressure per unit area	1.0	1.35	1.0
Motor Power	3	2.2	2.2
size	2070*1300*2230	640*1470*2000	570*1450*2100
Machine operation space(LXW)	3000*3000	2000*2500	2200*3500
Product size	1000*1000	500*500	400*400
weight	2200	1700	1300
low voltage electrical	CHINT	CHINT	CHINT
number of operators	2 persons /3sets	2	2
Every time the vulcanizing time	4-10min	4-10min	4-10min
Note	Column type	Column type	Column type

Detailed Photos
III. Our machine list
Our company professional manufacture rubber vulcanizing press (frame type,four column type,lab press and so on), rubber mixing mill, batch off cooler, rubber extruder, rubber strip making machine and tire recycling equipment.
IV. Our service
1. Test running: The above machines are all passed inspection of 3~5 hours of full load operation before leaving our factory. And we will take the video and send it to you for inspection. You can use it directly thus saving the time of test-run and expense. And we also warmly welcome to our factory to inspect and test running.
2.Warranty: 12 months after installation, if our machines have any problems, please feel free to contact me. We will solve it for you as soon as possible, and give you the best services.
