Automatic Paper Tube Machine for Sale CS-9/ID18-30mm/Max Length 620mm
| US$9,600.00-9,800.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
YOVON CS-9-620mm
Paper Core Usage
Instrument Package
Tube Machine Type
Bending Machine
Gumming Type
Single Side
Layers of Roll Paper
2 - 8
Reelpipe Speed
12 - 18m/minute
Wall Thickness of Paper Tube
1 - 5mm
Certification
CE
Condition
New
After-sales Service
1 Year
Brand
Yovon
Transport Package
Wooden Package
Specification
CS-9 parallel paper tube making mahcin
Trademark
YOVON CS-9
Origin
Liling Yovon Fireworks Machinery Factroy China
HS Code
8441100000
Production Capacity
200sets/Year
Product Description
YOVON cs-9 type tube making machine (full-auto)YOVON paper tube rolling machine
YOVON cs-9 type tube making machine (full-auto)
1. DETAIL MESSAGE:
full-auto paper tube making machine for fireworks. it can roll (full-auto) glue and cut tube and drop out tube on one machine. It needn't pump. The machine is used for producing parallel paper tube and then cut it into short tubes automatically. It consists of paper stand, gluing device (automatic cycle system with diaphragm pump), auto-water-adding system, paper cutting device, tube forming, tube-cutting and discharging device. The machine is equipped PLC screen and step motor send paper with machine.
2. Technical parameters
| Technical parameters CS-9 A type | |
| Number of roll paper | 3-10 layer |
| Tube ID | 18mm -30 mm |
| tube thickness | 1-4 mm |
| Applicable paper gram | 180-220gsm |
| Max. Paper tube length | 620mm |
| Roll core mold fixed | Three claws chuck |
| Winding head | 2 rolls of belts |
| Cutting tube mode | Single circular knife cutting |
| Glue way | Single sides |
| operation | 1 person |
| Paper delivery speed | 15-20 sheets/min |
| Speed control | transducer |
| Applicable glue | white glue/Tapioca starch glue |
| Input power | 6*1.1KW/380V/50HZ/3phases |
| weight | 1000 kg |
| Main frame size | 2200×2500×1400mm |
