Differential Scanning Calorimeter (DSC) Comply with ISO1157 and ASTM E794

Product Description

Product Description
Product DescriptionHY4510 Differential Scanning Calorimeter (DSC) is used to determine and research the melting and crystallization process, glass transition temperature, oxidation induction time (OIT), reaction heat, heat enthalpy, melting point, phase transition, etc. ModelAT451DSC range 0~±500mWTemperature range RT~800℃, air cooling (standard configuration)Heating speed 1~60℃/minTemperature resolution 0.1℃Temperature fluctuation ±0.1℃Temperature repeatability ±0.1℃DSC resolution 0. 05μWDSC accuracy 0.05μWDSC sensitivity 0.05μWTemperature control mode Heating up, keeping temperature, cooling down (program control)Display mode LCD touch screen Data interface USBPower supplyAC220V, 50HzDetailed Images★ Suitable for solid, powder and liquid samples, except gas sample. ★ LCD display, touch screen operation.The back of machine★ In-built atmosphere device, can simultaneously connect with Nitrogen and Oxygen, automatic switchover. With USB cable to connect machine to computer.★ Main machine control and software control, friendly operation interface, easy to operate.★ With gas flow meter, accurate to control the gas flow.Furnace★ Small furnace, high accuracy of temperature control, the temperature can be RT~800℃. Also, liquid nitrogen cooling system can be optional, the temperature can be -100 ~ 800℃ or -20 ~ 600℃.Two user interface on software, one is for DSC test, the other is for OIT test.Test interface for OIT testDSC-Temp curve for melting point test★ Real-time record and display DSC-Temp curve or DSC-time & Temp-time curve.DSC-Temp curve for glass transition temperature test★ Full equipped with accessories, convenient and easy to test.★ Chinese or English operation system can be selected.Packing & DeliveryPackagingSize(cm)64(L) * 58 (W) * 46 (D)Weight24 KgPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. Contacting usERIC QINWebsiteMobile Phone+86 188 5510 5986Whatsapp+86 188 5510 5986Skype eric-qlkWechat+86 188 5510 5986Our CompanyHistorySince 1982 with more than 20 years' experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most product
