Competitive Price Water Supply PVC Pipe Production Line
| US$22,000.00-68,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
SJ51
Product Type
Extrusion Molding Machine
Feeding Mode
One Feed
Assembly Structure
Separate Type Extruder
Screw
Twin-Screw
Engagement System
Full Intermeshing
Screw Channel Structure
Deep Screw
Exhaust
Exhaust
Automation
Automatic
Computerized
Computerized
Certification
ISO9001
Transport Package
Film
Specification
25*1.5*3.5m
Trademark
HYD
Origin
Shandong, China
Product Description
PVC pipe production line / PVC tube making machineDescription of PVC pipe makign machine
PVC pipe extruder machine/UPVC pipe making machine is mainly used in the manufacturer of the UPVC and PVC pipes with various tube diameters and wall thickness such as agricultural and constructional plumbing, water supply and drain etc. This set is composed of conical twin-screw extruder,vacuum calibration tank, hual-off machine,cutter, stacker etc.
Our machine can produce the PVC pipe with diameter from 16-630mm.
Main parameter of PVC pipe making machine
| Model | pipe range(mm) | extruders | max.speed(m/min) | total power(kw) | max.output(kg/h) | line length(m) |
| PVC-50*2 | 16-50 | SJSZ51/105 | 6 | 60 | 150 | 20 |
| PVC-63 | 16-63 | SJSZ45/90 | 10 | 45 | 120 | 20 |
| PVC-110 | 50-110 | SJSZ51/105 | 6 | 60 | 150 | 24 |
| PVC-160 | 63-160 | SJSZ65/132 | 5 | 100 | 300 | 24 |
| PVC-250 | 110-250 | SJSZ80/156 | 3.5 | 120 | 400 | 28 |
| PVC-315 | 160-315 | SJSZ80/156 | 3 | 160 | 400 | 36 |
| PVC-450 | 250-450 | SJSZ92/188 | 1.5 | 200 | 700 | 36 |
| PVC-630 | 315-630 | SJSZ92/188 | 0.9 | 230 | 700 | 36 |
Machine details
Our customer&exhibition
Packing
