Pipeline Anti Corrosion Heat Shrink Sleeve/Tape/Wrap Polyethylene

Product Description

Pipeline Anti Corrosion Heat Shrink Sleeve/Tape/Wrap polyethylene
HSSC-1 Heat shrinkable sleeve (2 layers), which are developed and manufacture by Qingdao Huashida machinery Co., Ltd for anti-corrosion of pipeline, are the composition of radiation cross-linked polyethylene backing and high shearing strengthen melt adhesive, and have the function of shape memory. The hot melt adhesive is squeezed into the joint by the shrink power to form a perfectly sealed surface, after being heated. HSSC-1 is compatible with standard pipe coating, also can be used for coating bare, replacement pipe sections and large radius bends. The system is designed to be applied with minimum preheating and is ideal for large diameter wastewater pipe.
Feature
Fast shrinkage speed, good waterproof performance, good anti-corrosive performance, long service life, convenient transportation and fast construction. The product is the ideal material for corrosion prevention and insulation.
Raw material with high quality
Specifications
---3 Layer PE Coating Pipe
---Offeshore &Underground
---Oil, Gas,Water pipeline
---DIA2''-72''
---Pipeline size: from Ø 108 to Ø 1554 ( 4''---60'')
Sleeves width: 100mm, 150mm,200mm, 300mm,450mm,500mm,600mm,900mm
Closure patch: 100mm, 150mm,200mm (4'', 6'', 8'')
Application scope
It's mainly used for heat pipe network, steel pipe corrosion resistance and insulation, chemical pipes and sewage pipes, etc
Technical paramenters:

	ITEM	Standard	UNIT	Data
Adhesive	softening point	ASTM E 28	°C	70-80
	shear strength	DIN 30 672	N/cm	≥100
Basic	specific density	ASTM D792	r/cm 3	0.935-0.96
	tensile strength	ASTM D638	Mpa	15-20
	Elongation at break	ASTM D792	%	350
	hardness	ASTM D2240	ball	48
Heat Shrinkable Sleeve	peel strength	ASTM D1000	N/cm	>150
	water-intake rate	ASTM D570	%	0.05
