Ecas-S500 Automatic Scissor Lift Platform with a Working Table Expansion

Product Description

ECAS-S500 Motorized Vehicle for High-Place Works Platform Orchard Platform Product Description

Feature and Performance
-One charge (3-4 days of use) is suitable for handling and high-altitude use.-Equipment can also be used on rainy days.-Rated loading capacity 800 kg 33 control boxes (maximum working height (39 meters) when loading in 3 stages)-Load case cover function Ramp level function.
Product Parameters

Major Specification:

Item	Description	Item	Description
Name of Machine	Aerial Lift Trailer	Weight of Vehicle (Weight)	1000kg
Type	ECAS-S500	Max Load(kg)	800kg
Dimension(LengthxWidthxHeight)	2760x1260x1330mm	Running Method	Infinite Track Type(Driven by a motor )
Upon extension of the extended table(mm)	1440mm	A driving motor Type	48V 2KW
Max.ascending height(mm)	2000mm	An illumination type	A lever type (a Joystick)
The height up to working table upon max descending (mm)	800mm	Running Speed(Km/h)	0-5km/h
A horizontal angle of the left ,right and the front	10°	Type of Hydraulic Device	Hydraulic Power Pack (The highest oil pressure 15MPa)

A driving level anyone could be operate .Manufactured in a double cylinder method.
Available for safe working without change the frame.The product include a working table expansion,a avaible for multipe persons to work ,automatic level adjustment,adjustable level atomatically according a slope etc.

Detailed Photos
1. Energy saving and environmental protection.2. Flexible operation.3. Easy access to the orchard.4. Crawler-type walking runs smoothly
Application scenarios
Product Action:
1. As you can see, this model can help you pick fruit like cherry ,apple,orange etc in bulk and complete efficient picking operations. Such wheeled transportation can only be widely supported by most fruit farmers if it has the characteristics of convenient operation, lightness and flexibility, safe running speed, and certain overload capacity.2.At the same time, it can help you prune fruit trees, remove redundant branches, ensure the light of the main pole, so that the branches can grow outward, and supervise the growth status of fruit trees.

Applicable scenarios: Industry / Agriculture / HouseholdPicking fruits and vegetables/House maintenance or construction/Warehouse/Outdoor and so on.

Exhibiting pictures


Package and Delivery

One charge, 5-6 days of use Wireless remote control (for upper and lower computers) Motors, chargers (self-produced semi-permanent) improve safety through ground design Electronic diagnostic instrument (no fault, upgrade)

Company Profile
Anhui Ekofil Autopats Co., Ltd. We are mainly engaged in the production of forklifts, electric handling equipment, and golf cart accessories, and are committed to the production and sales of agricultural machinery, with 17 years of industry experience.
FAQ
Q1.Can I have a sample order?A: Yes, we welcome sample orders to test and check quality.
Q2. Do you have any MOQ limit?A: Small quantity is accepted, but we offer a quantity discount.
Q3. How do you ship the goods and how long does it take to arrive?A: We usually ship by DHL, UPS, FedEx, or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping are also optional.
Q4. What does after-sales look like?A: We support 1 year of after-sales service.
Q5. Do you test all your goods before delivery?A: Yes, we have 100% test before delivery.
Q6. Is it OK to print my logo on the product?A: Yes. Please inform us formally before our production and confirm the design first based on our sample.
Q7. Does it support changing data?A: Yes. Please send the data you want, and we will send you the video after debugging and send it to you after confirmation.Q8. How to transport? Will it be damaged?
A: We provide shelf fixation and protection, to ensure product integrity.
