Automatic Silk Screen Printing Machine

Product Description

NONWOVEN SCREEN PRINTING MACHINE (1-3 COLORS)
Characteristics:
Description:
It is integrated with mechanic, electric and pneumatic system. It adopts silk screen printing technology and the latest web-to-web production line, improving the production capacity and quality of product, reducing the costs of the finished products. It is widely applied to textile print the non-woven fabric, clothes, sheets, towels and bath towels with water gel, glue and hot solidifying ink.
Characteristics:
1. It is equipped with textile printing conveyor belt: High speed rotation with stable operation and accurate positioning for the user to clean and replace the silk screen.
2. It is convenient for the user to clean and replace the silk screen.
3. Adjustable angle and printing pressure of doctor. Single color printing unit can be operated separately
4. Adjustable size of transverse printing route.
5. The printed products can be directly dried on the channel. It can be connected to the drier and transverse cutter in the back.
6. Human-computer interface controlling system.
If you need non-woven bag making machine. Please click here
Main Technical Variables:The main technical parameters:

MODEL	YS-1200
MAX.PRINTING SIZE	1200*1100mm
MAX.MATERIAL WIDTH	1280mm
MATERIAL GSM	35g-120g
MAX.ROLL DIAMETER	900mm
CAPACITY	SINGLE COLOR 990-1600m/h DOUBLE COLORS 600-1300m/h
VOLTAGE, TOTAL POWER	380v,60kw
MACHINE DIMENSION	7200*2200*2500*2MM
PRINTING PROCESS	UNWINDING+PRINTING+DRYER+PRINTING+DRYER+REWINDING
MACHINE WEIGHT	7000KG
REGISTION ERROR	WITHIN 1mm

The biggest feature of this machine: The machine has two modes, which can be used for dual color or single color mode.
