Swiss type CNC lathe machining case or part
| US$46,000.00-110,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SZ-205E2
Control Method
Semi-Closed Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01mm
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Control System
FANUC (OP Mitsubishi)
Guide bush mode & Non guide bush mode
Switchable
Transport Package
Standard Export Wooden Case
Specification
2180mm*1280mm*1865mm
Trademark
SOWIN
Origin
China
HS Code
8458110090
Production Capacity
500
Product Description
Brief Description of Model SZ-205E2 : Origin: Shenzhen, China Certification: CE Max Machining bar diameter: Φ20mm Dual spindles Main spindle: HAOZHI (China) FANUC 0i-TF Plus system (Japan) Accuracy: 0.01mm (Depend on specific workpiece) Electrical components: Schneider X1 travel: 90mm; X2 travel: 350mm;Y1 travel:340mm; Y2 travel:60mm; Z1 travel:240mm; Z2 travel:220mm; Suit for solving of Complicated, High-precision and Mini Parts High Efficient and Diversified Machining, Compound Machining: Turning, Milling, Drilling, Tapping Modular Tools Layout, Multi-axis Combined Operation; Stable, High-speed, Highly-efficient, Easy OperationProduct photo
Cutting tool layout
Technical parameter
Components
Certificate
Customers photo
Packing and Shipping
