Hydraulic Radial Arm Drilling Machine Metal Radial Driller Machine Hc-1200

Product Description

Hydraulic Radial Arm Drilling Machine Metal Radial Driller Machine HC-1200
1. Strong drilling ability, Mehanna tough cast iron, high temperature tempering, rigid and tough.
2. The gear is made of alloy steel, by quenching and carburizing heat treatment.
3. The spindle is made of chrome-molybdenum, diamond,outstanding durability.
Specification

Model			HC-1200
Distance between spindle centerandcolumn center		max	1200
		min	260
Distance between spindle nose to base		max	1200
		min	300
Diameter of spindle		E	270
Height of column		F	2055
Max distance between spindle head to base		G	2400
Floor space		HXI	1850*850
Longitudinal travel of spindle head		K	840
Up and down travel of radial ram		L	680
Up and down travel of spindle		M	220
Spindle hole		MT	No.4
Size of worktable		mm	1160*750
Motor of spindle		kw	2.25(2HP)*4P
Elevator motor of radial ram		kw	0.75(1HP)*4P
Motor for clamping		kw	-
Spindle feed range		mm/rev	0.05-0.16
		Grade	3
Spindle rotation		60HZ rpm	88-1500
		50HZ rpm	72-1243
		Grade	6
Working capacity		Drilling	42
		Taping (S45C)	24
Net Weight		kg	1750
Gross Weight		kg	1930
Dimension		mm	2050*950*2350
