100m 8+2+1SFP Electric Poe Switch OEM/ODM Poe Switch 4 8 16 24 Ports

Product Description

1000m 8+2+1SFP electric Poe switch

project	parameter
port	8 10/100base-t Poe ports Two 10/100base-t uplink ports 1 SFP optical port uplink
Switching performance	Backplane bandwidth: 2.8g MAC address table: 2K Support store and forward
Standard protocol	IEEE802. 3, IEEE802. 3i 10Base-T, IEEE802. 3u 100Base-T, IEEE802. 3x Flow Control, IEEE802. 1q VLAN, IEEE802. 3af PoE, IEEE802. 3at PoE+
Transmission medium and distance	Class V line: 100m in normal mode; Ultra long distance transmission mode: 250m
Poe	Poe ports: 8 DC48V, single port MAXIMUM POWER 30W Power supply line pair: 1/2 (+), 3/6 (-)
Power Supply	Ac100~240v 50/60hz input Total power 120W
indicator light	P: Power indicator, s: ultra long distance transmission mode indicator, V: VLAN mode indicator; POE: port 1~8 Poe indicator, link: port 1~10 electric port connection indicator
Use environment	Operating temperature: -10~+55 ºC Storage temperature: -40~+70 ºC Operating humidity: 10~90% non condensing Storage humidity: 5~90% non condensing
physical characteristics	Size (W x D x H): 200x120x44mm Weight: 1kg

HK-PM-F1R10 1000M Poe switch provides 8 1000m Poe ports and 2 1000m electrical ports and 1 SFP optical port uplink. It is an economical small-scale switch, which is widely used in small networks and monitoring systems such as homes and enterprises.
HK-PM-F1R10 1000M Poe switch supports ieee8023af and ieee8032at Poe standard can provide up to 30 watts of power to Poe webcam, wireless AP, Internet phone and other point receiving devices through one network cable, especially suitable for occasions where power wiring is inconvenient.
HK-PM-F1R10 1000M Poe switch has a unique dial switch design, providing one key isolation (VLAN) mode and one key ultra long distance transmission mode. In VLAN mode, ports 1~8 are isolated from each other to prevent DHCP spoofing, suppress broadcast storms, and improve network security; In the ultra long distance transmission mode, the port provides 10m full duplex transmission up to 250m, breaking the 100m transmission limit of the network cable and expanding the application scenario. International famous brand chips are adopted, with stable and reliable performance Provide 8 10/100base-t Poe ports and 2 10/100base-t uplink ports Support ieee8023af/at Poe Ethernet power supply standard, single port maximum output power 30W 2G backplane bandwidth, high-speed and smooth data exchange Support one click VLAN and ultra long distance transmission, and adapt to different application scenarios Built in power supply design, stable and reliable, providing 120W maximum power Lightning protection and surge protection, short circuit protection, overvoltage and undervoltage protection, safe and reliable Compact appearance, plug and play, simple maintenance
