Active Phased Array Detection Radar with Gsr 215-1c
| US$24,000.00-30,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
GSR 215-1C / C Band
Installation Mode
Radar Monitoring
Certification
ISO
Application
Communication Electronic Products
Working Mode
Phased Array + Pulse Doppler
Detection Range
2.5km (Pedestrians) 5km (Vehicles)
Elevation Coverage
9 Degree
Azimuth Coverage
90 Degree
Transport Package
Aluminum Alloy Package
Specification
C Band (5.5-5.8GHz)
Trademark
OEM
Origin
China
Production Capacity
1000 Piece/Year
Product Description
Ground Surveillance RadarGSR 215-1C / C Band
GSR 215-1C is a phased array radar with advanced technology and stable performance to realize the detection of moving targets on the ground.
Features -- High data rate and high positioning accuracy -- Multi-Input Multi-Output (MIMO) system -- All-weather adaptability
Application
Border, oil field, prison and other key areas security surveillance.
Specification
| Item | Specification |
| Working mode | Phased array + Pulse Doppler |
| Working frequency | C band (5.5-5.8GHz) |
| Detection range | 2.5km (Pedestrians) 5km (Vehicles) |
| Minimum detection range | ≤100m |
| Azimuth coverage | Single panel: 90° ( Dual panel:180°, 3-panel:270°, 4-panel:360°) |
| Elevation coverage | 9° |
| Distance accuracy | ≤10m |
| Azimuth Accuracy | ≤1.0° |
| Target detection speed | 0.2m/s - 30m/s |
| Speed precision | ≤0.2m/s |
| Data rate | ≤1.5s |
| Net weight | ≤4.8kg |
| Power supply | AC220V/40W (Single panel) |
| Interface | Ethernet (UDP protocol) |
| Dimension | 432mm x324mm x 79mm |
| Working temperature | -40 ºC ~ +60 ºC |
| Working Environment | Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof |
Factory preview
Project reference
